KUSSMAUL 091-150 Instruction Manual

Auto pump timer
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

FILE: 091-150
DATE: 06-05-02
REV.
INSTRUCTION MANUAL
AUTO PUMP TIMER
A TIMER TO LIMIT THE RUNNING TIME OF THE
AUTO PUMP
MODEL# 091-150
INPUT: 12VOLTS, D.C.
OUTPUT RELAY: 30 AMPS
3 YEAR WARRANTY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 091-150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KUSSMAUL 091-150

  • Page 1 FILE: 091-150 DATE: 06-05-02 REV. INSTRUCTION MANUAL AUTO PUMP TIMER A TIMER TO LIMIT THE RUNNING TIME OF THE AUTO PUMP MODEL# 091-150 INPUT: 12VOLTS, D.C. OUTPUT RELAY: 30 AMPS 3 YEAR WARRANTY...
  • Page 2 INTRODUCTION The Model 091-150 Auto Pump Timer limits the duty cycle of the Auto Pump to 1 hour on and 1 hour off. This is important to the life of the pump when it is operating on a vehicle with an abnormally high leak. The unit prevents the pump from operating at higher temperatures, and thus preserves the long life characteristics of the pump.
  • Page 3 SPECIFICATION AND OUTLINE Input Power: 12VDC (from Pressure switch input to relay COM). Input Current Draw: 80 ma. with pump running, 10 ma. with pump resting. Relay Contact Rating: 30 amps @ 14 VDC Weight: 4 ounces 5.10 3/16" DIA. 2.95 1.55 4,50...
  • Page 4 A u to P u m p A ir C o m p re s s o r 091-150 Note: AUTO PUMP TIMER make sure the Auto Pump is mounted N.C. vertical. N.O. C h a s s i s...
  • Page 5 Vehicle Owner WARRANTY All products of Kussmaul Electronics Company Inc. are warranted to be free of defects of material or workmanship. Liability is limited to repairing or replacing at our factory, without charge, any material or defects which become apparent in normal use within 3 years from the date the equipment was shipped.
