Sharp PN-P Series Operation Manual
S-format command
Related Manuals for Sharp PN-P Series
Summary of Contents for Sharp PN-P Series
- Page 1 PN-M432/PN-M502/PN-M552/PN-M652 /PN-P436/PN-P506/PN-P556/PN-P656 LCD MONITOR OPERATION MANUAL for S-Format command PN-P6-M2 OM1 EN(1)
-
Page 2: Controlling The Monitor With A Computer (Rs-232C)
Controlling the Monitor with a computer (RS-232C) Communication conditions You can control this monitor from a computer via RS-232C (COM port) on the computer. Set the RS-232C communication settings on the computer to match the monitor’s communication settings as follows: TIPS Please refer to "Controlling the monitor via RS-232C"... -
Page 3: Controlling The Monitor With A Computer (Lan)
Controlling the Monitor with a computer (LAN) You can control this monitor from a computer via network. Command control via normal TIPS communication. • Please refer to "Controlling the monitor via LAN" in the user manual. (1) Connect the computer to the monitor. •... -
Page 4: Communication Procedure
Communication Procedure ◼ Response code format ◼ Command format When a command has been executed correctly When a command is sent from the computer to monitor, the monitor operates according to the received command and Return code sends a response message to the computer. , 0A A response is returned after a command is executed. - Page 5 ◼ ◼ Repeater control Repeater controllable command list This system has a function to allow setting of multiple monitors Repeater controllable commands are listed below. connected in a daisy chain using a single command. * For details on each command, refer to the S-Format This function is called repeater control.
- Page 6 S-Format Command table Command table How to read the command table Command: Command field (See page 4.) W When the “Parameter” is set in the parameter field (see page 4), the command functions as described Direction: under “Control/Response Contents”. R The returned value indicated under “Reply” can be obtained by setting “????” or “ ?”...
- Page 7 Function Command Direction Parameter Reply Control/Response contents SHARPNESS SHRP 0 : 0 1 : 10 0 - 10 0 - 10 … 10 : 100 1 – 4, 11 1 – 4, 11 1: WIDE, 2: Normal, 3: Dot by Dot, 4: Zoom, 11: FULL ASPECT SETTINGS WIDE AMBIENT LIGHT SENSING -MODE...
- Page 8 SLOT menu Function Command Direction Parameter Reply Control/Response contents AUTO SHUTDOWN CCOP 0 - 1 0 - 1 0: OFF, 1: ON PROTECT menu Function Command Direction Parameter Reply Control/Response contents POWER SAVE PMNG 0 - 1 0 - 1 0: OFF, 1: ON QUICK START QUST 0 - 1...
