Whirlpool AGB 597/WP Instructions For Installation, Use And Maintenance Manual page 11

mA Line input terminal board
mC Commutating terminal board
B1 Switch
B2 Microswitch
C1 Safety contactor
C2 Adjusting contactor
F1 Adjusting thermostat
F2 Safety thermostat
H1 Green pilot lamp
H2 Orange pilot lamp
R Resistance
005 - 03 - Electric fryer
Wiring diagrams
AGB 524/WP
2 4
6
R
1 3 5
1 2 3 4 m
mC
C2
C1
mA 1 2 3 4 5
L1 L 2 L 3 N
400V 3N
mA 1 2 3 4 5
L1 L 2 L 3
230V 3
B2
F2
H1
B1 F1
6
PE
1
6 2 4
6
mC 1
PE
11
H2
3 5
2 3 4
