005_03 06/2007 Instructions for installation, use and maintenance ELECTRIC FRYER AGB 597/WP · AGB 521/WP AGB 515/WP · AGB 598/WP AGB 523/WP · AGB 516/WP AGB 522/WP · AGB 514/WP AGB 524/WP · AGB 525/WP...
Page 2
INDEX Models and dimensions Cleaning and taking care page of the appliance page Technical data What to do if not using the appliance for a long time Installation instructions What to do if something goes wrong Installation Maintenance Legal and technical requisites Installation WEEE Directive Wiring...
Page 3
B E D B E D B E D AGB 514/WP AGB 598/WP AGB 516/WP AGB 597/WP AGB 515/WP 400 x 700 x 510 600 x 650 x 270 600 x 700 x 510 400 x 650 x 270 400 x 650 x 270...
FRYER Model Dim.: LxWxH Nennspannung Power Anschlusskabel Querschnitt AGB 597/WP 400 x 615 x 300 400 V 3N oder 230 V 3 7.5 kW 5 x 1.5 mm oder 4 x 2.5 mm AGB 521/WP 400 x 700 x 875 400 V 3N oder 230 V 3 7.5 kW...
INSTALLATION INSTRUCTIONS Before beginning installation, remove all packaging from Installation the appliance. Some parts are protected with an adhesive Installation, start-up and maintenance should only be car- film which should be carefully removed. ried out by expert personnel. All work required to install Any remnants of glue should be thoroughly cleaned using the appliance should be carried out in compliance with all suitable substances such as benzine.
USING THE APPLIANCE Warning! CLEANING AND TAKING CARE OF THE MACHINE - Beware of inexpert handling! - Old and dirty oil or frying fat can represent a real fire Warning! hazard; make sure only new oil or frying fat are used each time you start frying.
THE 2002/96/EC DIRECTIVE (WEEE): information to users This informational note is meant only for owners of equipment marked with the symbol shown in Fig. A on the adhesive label featuring the tech- nical specifications applied on the actual pro- duct (the label also giving the serial number). This symbol indicates that the product is classified, ac- cording to the regulations in force, as an item of electrical and electronic equipment and conforms to EU Directive...
Wiring diagrams Line input terminal board Commutating terminal board 400 V 3N Switch Microswitch Contactor AGB 597/WP Working thermostat Safety thermostat AGB 521/WP Green pilot lamp AGB 515/WP Orange pilot lamp Resistance AGB 598/WP AGB 523/WP AGB 516/WP 400 V 3N...
Page 9
Wiring diagrams Line input terminal board Commutating terminal board Switch 230 V 3 Microswitch Contactor Working thermostat AGB 597/WP Safety thermostat AGB 521/WP Green pilot lamp Orange pilot lamp AGB 515/WP Resistance 230 V 3 AGB 598/WP AGB 523/WP AGB 516/WP...
Page 10
Wiring diagrams AGB 522/WP AGB 514/WP 22 23 22 23 11 12 13 11 12 13 P1 P2 P1 P2 L1 L 2 L 3 N 400V 3N L1 L 2 L 3 230 V 3 Line input terminal board Switch Microswitch Thermostat...
Page 11
Wiring diagrams AGB 524/WP L1 L 2 L 3 N 400V 3N L1 L 2 L 3 230V 3 Line input terminal board Commutating terminal board Switch Microswitch Safety contactor Adjusting contactor Adjusting thermostat Safety thermostat Green pilot lamp Orange pilot lamp Resistance 005 - 03 - Electric fryer...
Page 12
Wiring diagrams AGB 525/WP L1 L 2 L 3 N 400V 3N L1 L 2 L 3 230V 3 Line input terminal board Commutating terminal board Switch Microswitch Safety contactor Adjusting contactor Adjusting thermostat Safety thermostat Green pilot lamp Orange pilot lamp Resistance 005 - 03 - Electric fryer...
Page 13
BLE IF THE INSTRUCTIONS CONTAINED IN THIS MA- NUAL ARE NOT OBSERVED. THIS DOCUMENTATION IS ONLY INTENDED FOR QUALIFIED TECHNICIANS WHO ARE AWARE OF THE RESPECTIVE SAFETY REGULATIONS. WHIRLPOOL EUROPE srl V.le Guido Borghi, 27 I – 21025 Comerio – VA 005 - 03 - Electric fryer...
