Setting Oven Controls
To Set the Sabbath Feature (for use on the Jewish Sabbath & Holidays)
The BAKE TIME and START TIME pads are used to set the Sabbath feature. The Sabbath feature may only be used
with the BAKE pad. The oven temperature may be set higher or lower after setting the Sabbath feature (the oven
temperature adjustment feature should be used only during Jewish Holidays), however the display will not visibly show or
provide any audible tones indicating whether the change occurred correctly. Once the oven is properly set using Bake
with the Sabbath feature active, the oven will remain continuously ON until cancelled. This will override the factory
preset 12-Hour Energy Saving feature.
If the oven light will be needed during the Sabbath, press OVEN LIGHT pad before activating the Sabbath feature. Once
the oven light is turned ON and the Sabbath feature is active, the oven light will remain ON until the Sabbath feature is
turned OFF. If the oven light needs to be OFF, be sure to turn the oven light OFF before activating the Sabbath feature.
IMPORTANT NOTES: It is not advised to attempt to activate any other program feature other than BAKE while the
Sabbath feature is active. ONLY the following key pads will function after setting the Sabbath feature; UP or DOWN
ARROW, BAKE, START & CLEAR/OFF pads. ALL OTHER KEYPADS will not function once the Sabbath feature is
properly activated.
To Program the Oven to Begin Baking Immediately & activate the Sabbath feature
1. Be sure that the clock is set with the correct time of day.
2. Place the food in the oven.
3. Press BAKE pad. "---" will appear, "UPPER" and "BAKE" will flash in the display.
4. Press the UP or DOWN ARROW pad until the desired temperature appears. "UPPER" and "BAKE" will flash in the
display.
5. Press START pad or wait 5 seconds. "UPPER" and "BAKE" stop flashing and the icon will appear in the display.
6. If you desire to set the oven control for a Timed Bake or Delayed Start Bake do so at this time. If not, skip this
step and continue to step 7. Refer to the Timed Bake (complete steps 6-8) / Delayed Start Bake (complete steps 6-
9) section for complete instructions. Remember the oven will shut down after using Timed Bake or Delay Start Bake
and therefore may only be used once during the Sabbath/Jewish Holidays. The maximum Delayed Start Bake time
is 11 hours & 59 minutes.
7. The oven will turn ON and begin heating.
8. Press and hold both the BAKE TIME and START TIME pads for at least 3 seconds. SAb will appear in the display.
Once SAb appears in the display the oven control will no longer beep when a keypad is pressed or display any
further changes. The oven is properly set for the Sabbath feature.
Note: You may change the oven temperature once baking has started by pressing BAKE pad, the UP or DOWN
ARROW pads for the temperature you want and then pressing START pad TWICE (for Jewish Holidays only).
Remember that the oven control will no longer beep when a keypad is pressed or display any further changes
once the oven is set for the Sabbath feature.
9. The oven may be turned OFF at any time by first pressing CLEAR/OFF pad (this will turn the oven OFF only). To
turn OFF the Sabbath feature press and hold both the BAKE TIME and START TIME pads for at least 3 seconds.
This also turns off the oven. SAb will disappear from the display.
Should you experience a power failure or interruption, the oven will shut off. When power is returned the oven will not turn
back on automatically. The oven will remember that it is set for the Sabbath and the food may be safely removed from
the oven while still in the Sabbath feature, however the oven cannot be turned back on until after the Sabbath. After the
Sabbath observance turn OFF the Sabbath feature. Press and hold both the BAKE TIME and START TIME pads for at
least 3 seconds. SAb will disappear from the display and the oven may be used with all normal functions. For further
assistance, guidelines for proper usage, and a complete list of models with the Sabbath feature, please visit the web at
http:\\www.star-k.org.
(continued)
