Fig. 22: Loading the upper
- Glasses at the right and lefl hand sides. For "flu*" glasses use
the adjustable suppotts (see detail of Fig. C inside cover)
- Small plates in the middle
• Tea cups/coffee cups in double raw using the adjustable sup-
ports (see detail of Fig. C inside cover).
- Bowls in the front side.
- With long handles and tong knives in the upper basket (see
detail of Fig. C inside cove,)
- Fig. 23: Dishes with a diameter 25 cm (max) in the upper
basket, at the right hand side.
In this case it will be necessary to move the basket in the "Low"
position (Fig. 23-24).
Operate onthebasket h andles(A)andmove downwards a tthe
same time (direction )
After every load, it is necessary to check that the two spray
arms are free to rotate without any obstruction.
Adjusting the water pressure
The pressure of the water jets from theu per spray arm can be
adjus ted b y turni ng the wate r
High pressure (turn +) tor a normal load (e.g. cups, plates, small
plates, glasses).
LOW pressure (turn —) for a delicate load (e.g. very deficate
glasses).
3.3 Adding the detergent
Only use powder detergent specifically designed for domestic
dishwashers (powder or liquid detergent).
Add the detergent before any wash cycle, except for pro-
gramme "N. I" (rinse and hold cycle).
Procedure
Open the cover (Fig. 28).
Powder detergent (Fig. 29)
- Pour 7,5 grams of detergent (2 teaspoons) in the small com-
partment and 17,5 grams (4 teaspoons)
partment.
Liquid detergent
Half fill the compartments.
The above quantities are given as an indication only.
They refer to a normal programme.
For the other programmes, see the "Programme Chart".
- Close the cover (Fig. 30) until a click is heard.
The detergent drawer is equipped with a flap section (Fig. 30A)
and the detergent is dispensed
parlment when the dishwasher
This is to avoid the power detergent from going outside the
dishwasher.
Close the dishwasher door
Your new dishwasher is fitted with the unique D.P.C.
(Dynamic Performance Control) patented system, which
ensures excellent washing
adverse conditions such
- over foaming
• particialty blocked filter
- water trapped in an upturned
It senses any drop in pressure to the spray arms and
automatically restores it back
basket
rear side.
(Fig. 26-27)
l funne (Æ
in the large com-
from the pre-wash com-
door is closed
until a click is heard.
performance even under
as:
cup or sauce pan
to normal.
