CONTENTS
1 GENERAL DESCRIPTION
1.1 Control pane' (Fig. a)
1.2 Inside of tub (Fig. b)
INSTALLATION
2.1 Installation of the machine
2.2 Hydraulic and electric
2.3 Built-in models
E] US E OFTHE DISHWASHE R
3.1 Filling the rinsing aid reservoir
3.2 Loading the crockery into the baskets
3.3 Adding the detergent
3.4 Control panel, choice of the programme
3.5 How to operate the machine
4 MAINTENANCE
4.1 Cleaning the filters
4.2 Cleaning the spray arms
E] MAI N TECHNIC AL DATA
TROUBLE SHOOTING
OF THE DISHWASHER
connections
GUIDE
DESCRIPTION OF THE DISHWASHER
I .1 Controt panel (Fig. a) page I
A) Operation lamps
B-C) Push-buttons: Economy/Quick
D) Door handle (to be pulled)
E) Programmes selector and on/off knob (to be turned in the
direction marked, only).
Note: For detailed informations on programmes selection and
function of buttons, please refer to chapter "Control panel,
choice of the programme".
1.2 Inside of tub (Fig. b) page 1
1 Service plate
2) Upper basket (adjustable in height)
3) Top spray unit
4) N. 4 supports/adjustable
5) Shower
6) Lower spray arm
7) Filter with micro-filter "Mi'
8) Two-compartments detergent dispenser: 7,5+17,5 g
9) Rating plate with technical data
10) Rinsing aid dispenser (capacity. 150 cc.)
1 1 ) Cutlery basket
1 2) Lower basket with racks
(A: soup plates; B: dinner plates; C: dessert plates)
INSTALLATION
We recommend you install the dishwasher in a fixed position
with independent electrical and hydraulic connections C).
The installation works requiring electrical and plumbing con-
nections must be carried out by qualified technicians in confor-
mity with local regulations.
The Manufacturer will accept
persons or objects arising
this requirement.
C) The electrical installation
2.1 Installation of the machine
Dishwashers fitted with a work top, have the following dimen-
sions (Fig. I):
- Height:
Depth:
- Width:
- Plinth height:
- Worktop thickness:
The height of the dishwasher can be adjusted from 845 mm.
min. to 860 mm. max. by means of the four feet (Fig. 2).
The work top can be adjusted frontwards by 20 mm. (Fig. 3)
using the two adjusting brackets
worktop (fig. 4):
- Remove screws (A), loosenscrews (b)
Turn by 1800 the brackets as in position C)
- Tightenscrews @ ; pushfrontwardstheworktop andfix it by
means of the screws A
To instan the machine under the washbasin
ter, it may be necessary to remove the worktop.
Remove the adjusting brackets
worktop,removescrews @and @ (Fig. 4),push frontwards
the top until it is disengaged from the sliding guides (Fig. 3).
The height of lhe dishwasher will then be 820 mm., and can be
adjusted from 815 to 830 mm.
Check that the machine is level (adjust if necessary the 4 feet -
Fig. 2).
buttons with pilot lamps
spacers
no liability for damage
from the non-observance
must be earthed.
850 mm
600 mm
594 mm
100 mm
30 mm
situated at the rear of the
or under the coun-
situated at the rear of the
to
of
2
