Capacity Chart; Product Assembly - Kitchenaid 5Ksm7990 Series Use And Care Manual

CAPACITY CHART

All-purpose flour
Bread
Cookies / Biscuits
Mashed Potatoes

PRODUCT ASSEMBLY

1
Turn the Stand Mixer to "OFF (0)" and
then unplug.
3
Locating pin
To attach the Bowl: Fit the Bowl
Supports over Locating Pins and press
down on back of the Bowl until Bowl Pin
snaps into spring latch.
4
To attach the accessory: Slip the
accessory onto the shaft. Turn to hook it
over the pin on the shaft.
8
W11457004A_01_EN.indd 8 W11457004A_01_EN.indd 8
6.9 L Bowl
Spring latch
Pin
2 to 2.2 kg
8 breads of 450 g
160 pieces
3.6 kg
2
Place Bowl-Lift Lever in down position.
IMPORTANT: If the Bowl is not securely
snapped into place, it will be unstable
and wobble during use.
5
To raise the bowl: Rotate the
Bowl-Lift Lever to the straight up
position. The Bowl must always be in the
raised position when mixing.
10/5/2020 3:20:47 PM 10/5/2020 3:20:47 PM
