Product Usage; Optional Attachments - Kitchenaid 5Ksm7990 Series Use And Care Manual

PRODUCT USAGE

OPTIONAL ATTACHMENTS

KitchenAid offers a wide range of optional attachments such as the Spiralizer, Pasta
Cutters, or Food Grinder that may be attached to the Stand Mixer attachment power
hub.
1
Turn the Stand Mixer to "OFF (0)" and
then unplug.
3
Insert attachment into Attachment Hub,
making certain that attachment power
shaft fits into the square Attachment Hub
socket.
5
Turn the Stand Mixer to
To remove:
"OFF (0)" and then unplug.
NOTE: See the Use and Care Guide of each specific attachment for more details.
W11457004A_01_EN.indd 11 W11457004A_01_EN.indd 11
2
Flip up hinge Attachment Hub cover to
open.
4
Tighten the Attachment Knob by turning
it clockwise until the attachment is
secured to the Stand Mixer.
6
Loosen Attachment Knob by turning it
counterclockwise. Rotate attachment
slightly back and forth while pulling it out.
