CONTROL PANEL

1
OPERATIONS AND DISPLAYS
Power
1
Press this button to turn on or turn off the dishwasher.
Start/Cancel
2
Once the door is firmly closed, press Start/Pause to start
operation after selecting the cycle and options or delay
time settings.
3 Wash Cycle Selections
• Auto
Auto sensing wash, lightly, normally or heavily soiled crockery,
with or without dried-on food.
• Heavy Duty
Heavy Duty cycle is for pots, pans, casseroles, and dinnerware
with dried-on or baked on soil.
• Normal
Normal cycle with Heated Dry will completely wash and dry a
full load of normally soiled dishes.
• Delicate
Delicate cycle is for items that need special care such as
stemware or porcelain.
• Express
Express Wash cycle is for lightly soiled or well-rinsed
dish loads.
• Rinse
Use for pre-rinsing dishes or glasses. This is only a rinse that
keeps food from drying on your dishes and reduces odor buildup
in your dishwasher until you are ready to wash a full load.
4 Options
Adaptive Option Indication
When a washing cycle is selected, default Option(s) are firmly lit. Also
available Option(s) the selected washing cycle are dimly lit for
your convenience.
• Half Load
When the load is about or less than half a typical load, use the
Half Load function, which washes and dries with less water
and energy.
• Hi Temp
When the "Hi Temp wash" function is selected, the temperature
of the water will be maintained at 60˚C (140˚F) max.
3 5
6
4
• Sanitize
When the "Sanitize" function is selected, the temperature of
water will be maintained at 69˚C (156.2˚F) max. The max
temperature may not be reached if the incoming water
temperature is not corrected. Certified residential
dishwashers are not intended for licensed
food establishments.
The sanitize option is available with
WARNING
"Auto" "Heavy" "Normal" and "Express" cycles.
• Auto Open
After washing, the door will open automatically to achieve
better drying effect. (It can only be used with Auto, Heavy,
Normal, Delicate, and Express).
Press and hold this button for 3 seconds to open or cancel
this function. When the icon lights up, the function of Auto
open is selected.
• Wash Zone
Press the button to select either upper basket or lower basket
loaded, and the corresponding indicator will light up.
• Delay +/Delay --
To delay the start of a selected cycle, press the Delay Start
pad until the desired delay time shows in the LED display.
Each press of the button changes in a cycle of
"00Hr~08Hr › 12Hr › 16Hr › 20Hr › 24Hr › 00Hr."
Each button from 00Hr to 08Hr increases by 1 hour, and
each button from 08Hr to 24Hr increases by 4 hours. To
cancel the delay start option before the delay period is over,
press the Start/Pause pad for 3-5 seconds.
• Child Lock
Press the button to lock all and prevent children from
accidentally interacting with controls or settings.
5 Display Window
• Time Indicator
This displays the remaining hours and minutes of the
running cycle, delayed hours, error codes, etc.
