Specifications Of Electrical Parts - Toshiba Ras-B13B2Kvg-E1 Service Manual

6-1. Indoor Unit
No.
1 Fan Motor (for indoor)
2 Room temp. sensor (TA-sensor)
3 Heat exchanger temp. sensor (TC-sensor)
4
Heat exchanger temp. sensor (TCJ-sensor)
5 Louver motor
6-2. Outdoor Unit
No.
1 Compressor
2 Fan Motor
3 4-Way valve coil
4 Discharge temp. sensor
5 Outside air temp. sensor
6 Heat Exchanger temp. sensor
7
Terminal block

6. SPECIFICATIONS OF ELECTRICAL PARTS

Parts name
Parts name
(TD sensor)
(TO sensor)
(TE sensor)
(5 poles)
Type name
WDF-340-30CA
(-)
(-)
(-)
24BYJ48-STHL
Type name
KSK75D15UEZA3
LDF-340-A43AA1-1
SQ-A2522G-000352
(Inverter attached)
(Inverter attached)
(Inverter attached)
JXO-5B
- 20 -
Specifications
DC 280-340V, 42W
10kΩ at 25°C
10kΩ at 25°C
10kΩ at 25°C
Output (Rated) 4 phase, DC12V
Specifications
3-Phases (6-Poles) ; 615W
DC 140-340V ; 43W
AC 220-240V
62kΩ at 20°C
10kΩ at 25°C
10kΩ at 25°C
AC 250V, 20A
