4-2. Outdoor Unit

(Unit : mm)
50
36
R15
11
6 hole
A detail drawing
(Back leg)
FAN-GUARD
P-FAN
Air inlet
63
500
97
A
Drain outlet
360

Front Side

Back Side

45 or more
100 or more
Air outlet
98
55
B
COVER-PV
Air inlet
600 or more
600 or more
- 18 -
11 x 14 hole
(For
8-10 anchor bolt)
6 hole
R15
36
50
B detail drawing
(Front leg)
Electrical part
Liquid side
(Flare
6.35)
Gas side
(Flare
9.52)
Service port
