BATHSELECT BS10128 Installation Instructions Manual
Touchless commercial automatic sensor faucet in matte black
Product code: BS10128
TOUCHLESS COMMERCIAL AUTOMATIC SENSOR FAUCET
IN MATTE BLACK INSTALLATION INSTRUCTIONS
PRIOR TO INSTALLATION
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
POSSIBLE TOOLS REQUIRED*
Level
Plumbers Tape
Tape Measure
Adjustable Wrench
Hex Wrench
Thread Sealant
Pencil or Marker
Screwdriver
Drill
*not included
bathselect.com
1
Customer Service: 800-500-9895
Related Manuals for BATHSELECT BS10128
Summary of Contents for BATHSELECT BS10128
- Page 1 Product code: BS10128 TOUCHLESS COMMERCIAL AUTOMATIC SENSOR FAUCET IN MATTE BLACK INSTALLATION INSTRUCTIONS PRIOR TO INSTALLATION Please read installation instructions below. All plumbing should be installed in accordance with applicable building codes and regulations. Unpack and inspect the items for any shipping damages. If you find damages, do not install.
- Page 2 Rubber Washer Washer Min: 1.26”/32mm - Max: 1.38”/35mm 1.38”/35mm Nut and locking bolts Deck Mount Type 1 Deck Mount Type 2 O ring Rubber Washer Washer Nut and locking bolts Sensor Cable Water flexible pipe Water Pipe bathselect.com Customer Service: 800-500-9895...
- Page 3 Remove the battery case from the control box and remove the screw from the center of the battery case. Insert 4 AA batteries (batteries not included) into the battery box ensuring they are inserted the correct way. bathselect.com Customer Service: 800-500-9895...
- Page 4 Tighten with a wrench. Connect the faucet hose to the control box, at the connection marked Outlet. Hot Water in Mixer Water out NPS male G1/2 NPS female G1/2 Water Supply Water Supply Outlet Inlet bathselect.com Customer Service: 800-500-9895...
- Page 5 Important: This flushes away any debris that could cause damage to faucet internal parts. 6. Connect waterlines to angle stops. Turn on the angle stops and check for leaks (DO NOT TURN FAUCET ON). 7. Turn the faucet on for 1 minute to flush any debris. bathselect.com Customer Service: 800-500-9895...
- Page 6 BathSelect are safe and comply to legislative requirements. Providing they are installed correctly and receive regular maintenance in accordance with these instructions your user experience will not be affected.
