DELONGHI K900FO
Owner's Manual
Shop genuine replacement parts for DELONGHI
K900FO
Find Your DELONGHI Air Conditioner Parts - Select From 155 Models
-------- Manual continues below --------

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K900FO and is the answer not in the manual?

Questions and answers

Related Manuals for DeLonghi K900FO

Summary of Contents for DeLonghi K900FO

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DELONGHI K900FO Owner's Manual Shop genuine replacement parts for DELONGHI K900FO Find Your DELONGHI Air Conditioner Parts - Select From 155 Models -------- Manual continues below --------...

  • Page 2: Important Safeguards

    8-07-2003 15:32 Pagina 4 Important Safe-guards When using electrical appliances, basic safety precautions should always be taken, with particular reference to the following: Read all instructions. To protect against fire, electric shock and personal injury, do not immerse cable, plug or appliance in water or other liquid.
  • Page 3 Each Pinguino can also be used as a fan only. For more details, contact: DE’LONGHI AMERICA INC. Tel: 1-800-322-3848 DE’LONGHI CANADA or visit our Internet site www.delonghi.com...

  • Page 4: Description Of The Appliance

    8-07-2003 15:32 Pagina 6 Description of the appliance DESCRIPTION MODEL 1) Air discharge grill 2) Control Panel 3) Wheels 4) Handles 5) Housing for air exhaust hose 6) Cord winder 7) Air intake grill 8) Rating plate 9) Water collection tank 10)Water drain tube 11)Stopper for drain tube 12)Power cord...
  • Page 5 8-07-2003 15:32 Pagina 7 S e t t i n g u p When positioning the appliance, always ensure that nothing obstructs the intake and discharge of • If you have a double window, use the AIR CONDITIONING WITHOUT PERMANENT suckers (16) supplied to keep the panes from INSTALLATION opening wide (figure 3).
  • Page 6 8-07-2003 15:32 Pagina 8 S e t t i n g u p Pinguino is equipped with an adjustable win- If you have a sliding door, use the additional dow bracket ( 18) . If you have a sliding win- set provided in order to extend the accessory dow, place the bracket on the window sill, to the desired length;...
  • Page 7 8-07-2003 15:32 Pagina 9 S e t t i n g u p • Fit the flange (13) supplied to the hole. AIR CONDITIONING WITH SEMI-PERMA- • Fix the hose (14) in the housing at the rear NENT INSTALLATION of the appliance (fig 1) If desired, Pinguino can also be installed on a •...

  • Page 8: Description Of The Control Panel

    8-07-2003 15:32 Pagina 10 Description of the control panel THE DISPLAY A. ON/OFF Button B. Function Button Air-conditioning, dehumidifying, ventila- tion C. Air-conditioning indicator light D. Dehumidifying indicator light E. Ventilation indicator light F. Increase temperature button / increase operating time button G.

  • Page 9: Switching The Appliance On

    8-07-2003 15:32 Pagina 11 O p e r a t i o n SWITCHING THE APPLIANCE ON Connect the appliance to the mains supply. On the display two lines will appear indicating Stand-by mode Press the ON/OFF button (A) and then the MODE button until the relevant function indicator appears viz.: Indicator C : air-conditioning...

  • Page 10: Programming The Timer

    8-07-2003 15:32 Pagina 12 O p e r a t i o n Once the dehumidifying function has been selected, the fan speed cannot be changed. The appliance will automatically “Silent” select the correct fan mode. speed VENTILATION Adjust the fan speed by pressing the “FAN” (Q) button, as illustra- ted in the air conditioning function.

  • Page 11: Self-Diagnosis

    8-07-2003 15:32 Pagina 13 O p e r a t i o n SELF-DIAGNOSIS The appliance is equipped with a self-diagnosis system which identifies any operating problems. IF THE DISPLAY SHOWS… ….WHAT SHOULD YOU DO? Insert and re-insert the plug. If the problem persists, call the service H H P P HIGH PRESSURE centre.
  • Page 12 8-07-2003 15:32 Pagina 14 R e c o m m e n d a t i o n s • Do not install the heater in humid environ- Follow these recommendations to achieve maximum efficiency from your air conditio- ments. ning unit: •...
  • Page 13 8-07-2003 15:32 Pagina 15 C l e a n i n g Before cleaning or maintenance, switch off the appliance by pressing the ON/OFF button (A) and always unplug it from the mains supply. CLEANING THE EXTERNAL UNIT We recommend cleaning the appliance with Dust filter a slightly damp cloth.

  • Page 14: Troubleshooting

    8-07-2003 15:32 Pagina 16 Troubleshooting PROBLEM CAUSES REMEDY The air-conditioner • the power is off • the appliance is not plugged in • Plug it in does not work The air-conditioner • The exhaust hose is twisted • Position exhaust hose correctly works only for a •...

  • Page 15: Technical Specification

    8-07-2003 15:32 Pagina 17 Technical specification TECHNICAL SPECIFICATION Power supply see rating plate OPERATING LIMITS Max. absorbed power Room temperature 69 - 95°F in air conditioning “ Max. absorbed power when dehumidifying “ Refrigerating capacity* “ Number of fan speeds 2 + silent Max.

  • Page 16: Limited Warranty

    8-07-2003 15:32 Pagina 18 Warranty FOR UNITED STATES ONLY: LIMITED WARRANTY We warrant each DE’LONGHI AIR-CONDITIONER to be free from defects in material and workmanship. Our obligation under this warranty is to provide one year parts and labor free from purchase date, with an additional four (4) years on any part of the sealed system con- sisting of the compressor, evaporator, condenser and factory connected refrigerant tubing.
