Note: 1.DP:3440x1440 (up to 144Hz), support FreeSync Premium and HDR technology.
2.HDMI1/HDMI2: 3440x1440 (up to 100Hz), support FreeSync Premium and
HDR technology.

Installation

To install the monitor on your host system, please follow the steps below:
Steps
Connecting Your Monitor to a Computer
1. Turn off your monitor and unplug your computer's power cord.
2. 2-1 Connect HDMI Cable (Option，Only HDMI-input model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer.
2- 2 Connect D P Cable (Optional, Only DP-input model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the DP cable to the computer.
3. Insert the monitor power cable into the power port at the back of the monitor.
4. Plug the power cords of your computer and your monitor into a nearby electrical outlet.
In order to prevent damage to the monitor, do not lift the monitor by its base.
HDMI1
HDMI2
DP
