Diamond Multimedia 3650PE512H Product Setup Sheet

DIAMOND MULTIMEDIA
SKU
SYSTEM BUILDER SKU
PRODUCT
PRODUCT SHORT
DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
3650PE512H
3650PE512HSB
Diamond Viper - ATI Radeon™ HD 3650 PCIE 512MB GDDR2 Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
DUAL MONITOR
DUAL LINK DVI
ATI Avivo™ HD Video & Media
The ATI Radeon HD 3000 Series of GPUs allow you to experience the power of HD with graphics processing
designed for how you work and play. The Diamond Radeon™ HD 3650 delivers outstanding performance at a
great price. Advance to the next generation of HD game performance and life-like realism thanks to DirectX® 10.1
capabilities and plug-and-play ATI CrossFireX™ multi-GPU upgradeability. Watch the latest Blu-ray videos in full
1080p HD and upscale beyond - without placing huge demands on your CPU. Enjoy break-through efficiency with
more processing performance per watt and energy-saving features to help save you money.
Superscale unified shader architecture
PCI Express x16 2.0 support
120 Unified Stream Processors
128-bit memory interface
Direct X 10.1 / Shader Model 4.1
ATI Crossfire X Multi-GPU Support for highly scalable performance
Up to four GPU support with an AMD 790FX based motherboard
High-speed 128-bit-HDR (High Dynamic Range) rendering
Up to 24x Custom Filter Anti-Aliasing
55nm process technology
ATI Avivo HD Video and Display Technology
Game Physics processing capability
Built-in HDMI with Multi-channel 5.1 surround audio
Unified Video Deoder (UVD) for Blu-ray
ATI PowerPlay energy conserving technology
RoHS compliant
Build in HDCP Support
OpenGL 2.0 Support
EXTERNAL POWER REQUIREMENT
SYSTEM REQUIREMENT CPU
SYSTEM REQUIREMENT CPU SPEED
SYSTEM REQUIREMENT MEMORY
SYSTEM REQUIREMENT POWER SUPPLY
SYSTEM REQUIREMENT SPECIAL INSTRUCTIONS
SYSTEM REQUIREMENT HARD DISK
SYSTEM REQUIREMENT BUS
SYSTEM REQUIREMENT STANDARD SLOT
SOLUTION
SYSTEM REQUIREMENT CHASSIS
SYSTEM REQUIREMENT MONITOR
Product Setup Sheet
DATE : June 18, 2008 - 1:15 pm
PCI Express x16
HD 3650
725 MHZ
800 MHz
16Mx32
GDDR2
80.6 GB/sec
512MB
128-Bit
Dual-Link DVI,HDMI,VGA
Hydravision 4
NONE
Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
2.0 Ghz or faster
1024MB
250 Watt or greater power supply .
ATI Radeon HD 3870 and ATI Radeon HD 3850 System
Requirements PCI Express® based PC is required with
one X16 lane graphics slot available on the motherboard
450 Watt or greater power supply for dual ATI
CrossFireX™) Certified power supplies are
recommended 1GB of system memory recommended
Installation software requires an optical drive DVD
playback requires DVD drive Blu-ray™ / HD DVD
playback requires a Blu-ray drive For a complete ATI
CrossFireX™ system, additional ATI Radeon™ HD 3800
series graphics card(s)and a ATI CrossFireX Ready
motherboard are required.
480MB available hard disk space
PCI Express
SINGLE
N/A
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
