Complete Installation
1. Insert the foam seal behind the top of the lower window sash and against the glass of the upper window.
A
2. Place the window lock bracket as shown. Use a
bracket and into the upper window.
3. Attach the window lock bracket to the upper window with one ³¹⁄32" screw to secure the window in place.
4. Plug into a grounded 3 prong outlet.
5. Press RESET on the power supply cord. See "Electrical Requirements."
ESA410J
A. Top of lower window sash
B. Foam seal
B
¹⁄8" drill bit to drill a starter hole through the hole in the window lock
12
Installation and Accessory Parts
Domestic Air Conditioner
