– In humid places
• If condensation occurs, turn the power off and leave it for about
two hours. Once the camera acclimatizes to the surrounding
temperature the condensation will go away naturally.
B

Supplied Accessories

Product numbers correct as of January 2017. These may
be subject to change.
1
Lens Pouch
2
Lens Cap
3
Lens Rear Cap
4
Lens Hood
• The lens rear cap and lens cap are attached to the
interchangeable lens at the time of purchase.
C

Names and Functions of Components

1
Lens surface
2
Focus ring
Rotate to focus when taking pictures with manual
focus (MF).
3
Zoom ring
Rotate the zoom ring when you wish to take large
(tele) or wide (wide angle) pictures.
4
[O.I.S.] switch
When the lens is attached to the camera the stabilizer
function is set to activate if the O.I.S. switch is set to [ON].
• We recommend setting the O.I.S. switch to [OFF]
when using a tripod.
5
[AF/MF] switch
This allows you to switch between Auto Focus (AF)
and Manual Focus (MF).
• When either the [AF/MF] switch of the lens or the
setting of the camera is set to [MF], Manual Focus
(MF) is enabled.
6
Lens fitting mark
7
Contact points
8
Lens mount rubber
Note
• When recording on the wide-angle side and using the
flash, the periphery of the screen may darken. In such
cases, we recommend using the external flash.
• If you zoom after focusing, focusing errors may occur.
After zooming, please perform the focusing again.
• In very quiet situations Auto Focus operating sounds
may be recorded during motion picture recording. This is
not a malfunction. In such situations, switching to
Manual Focus will improve the situation.
• If you set the O.I.S. to [ON] when recording a motion
picture, operating sounds may be recorded. If they
become bothersome, we recommend setting the O.I.S.
switch to [OFF] and mounting the camera on a tripod.
D

Attaching/Detaching the Lens

For information on how to attach and remove the lens,
refer to the operating instructions for your digital camera.
• Before attaching or detaching the lens, check that
the digital camera is turned off.
• Before attaching the lens to the digital camera, remove
the lens rear cap A by rotating it in the direction of the
arrow. (See illustration
• To prevent dust and other particles from accumulating on
or entering the lens, be sure to attach the lens cap/lens
rear cap after detaching the lens from the digital camera.
∫
Attaching Filters
• Vignetting may occur if using 2 or more filters at the same time.
• It is possible to attach the lens cap with the filter already
attached.
• When using the lens hood and a filter at the same time,
attach the filter first.
• You cannot attach a conversion lens or adaptor to this
lens. A filter may be used, but attaching any other
element may cause damage to the lens.
∫
Attaching the Lens Hood (Supplied Accessory)
(See illustration
Hold the lens hood with your fingers placed as shown
in the picture ( B ).
• Do not hold the lens hood in a way that twists or bends it. ( C )
1
Align the mark D (
the mark on the tip of the lens.
2
Rotate the lens hood in the direction of the
arrow until it clicks and then align the mark
E (
the tip of the lens.
∫
Removing the lens hood (See illustration
Rotate the lens hood in the direction of the arrow
while pushing the button F on the lens hood.
∫
Temporarily Storing the Lens Hood
(See illustration
1
Align the mark E (
with the mark on the tip of the lens.
2
Rotate the lens hood in the direction of the
arrow until it clicks into place.
Note
• When taking pictures with the flash with the lens hood
attached, the lower portion of the screen may turn dark
(vignetting effect) and the control of the flash may be
disabled because the photo flash may be obscured by
the lens hood. We recommend detaching the lens hood.

Cautions for Use

Take care not to drop or knock the lens. Also take care
not to put a lot of pressure on the lens.
• Take care not to drop the bag that you inserted the lens
in as it may strongly shock the lens. The camera may
stop operating normally and pictures may no longer be
recorded. Also, the lens may be damaged.
) on the lens hood with the mark on
)
/ )
) on the lens hood with
)
) on the lens hood
)
