– When detaching the lens from the digital camera, take
care to ensure that sand, dust, splashes of water etc.,
do not get into the lens or the terminals.
– This lens is not waterproof and cannot be used to record
underwater. For splash-proofing, the lens is constructed to
resist the entry of water. If splashes of water etc. do adhere
to the lens, wipe after use with a soft dry cloth.
• To improve the dust-proofing and splash-proofing of this lens, a
lens mount rubber is used in the mounting portion. After changing
the lens a number of times, you may find that the lens mount
rubber has marked the mount portion of the digital camera body,
which does not affect its performance. For information on changing
the lens mount rubber, contact your nearest Service Center.
• Do not press the lens with excessive force.
• When there is dirt (water, oil, and fingerprints, etc.) on the surface
of the lens, the picture may be affected. Lightly wipe the surface
of the lens with a soft, dry cloth before and after taking pictures.
• To prevent dust and other particles from accumulating on or entering
the lens, attach the lens rear cap when the lens is not in use.
• To protect the lens contact points 1, do not place the
lens with its mount surface facing down. In addition, do
not allow the lens contact points to become dirty.
(See illustration
∫
About Condensation (Fogging of the Lens)
• Condensation occurs when there are differences in
temperature and humidity as described below. Condensation
can cause the lens to become dirty and lead to mold and
malfunctioning, so exercise caution in the following situations:
– When the camera is brought indoors from outside
during cold weather
– When the camera is brought into an air-conditioned car
– When cold air from an air conditioner is directly blown
onto the lens
– In humid places
• If condensation occurs, turn the power off and leave it for about
two hours. Once the camera acclimatizes to the surrounding
temperature the condensation will go away naturally.
B

Supplied Accessories

Product numbers correct as of January 2017. These may
be subject to change.
1
Lens Pouch
2
Lens Cap
3
Lens Rear Cap
4
Lens Hood
• The lens rear cap and lens cap are attached to the
interchangeable lens at the time of purchase.
Names and Functions of
C
Components
1
Lens surface
2
Focus ring
Rotate to focus when taking pictures with manual
focus (MF).
3
Zoom ring
Rotate the zoom ring when you wish to take large
(tele) or wide (wide angle) pictures.
4
[O.I.S.] switch
When the lens is attached to the camera the stabilizer
function is set to activate if the O.I.S. switch is set to [ON].
• We recommend setting the O.I.S. switch to [OFF]
when using a tripod.
5
[AF/MF] switch
This allows you to switch between Auto Focus (AF)
and Manual Focus (MF).
• When either the [AF/MF] switch of the lens or the setting of
the camera is set to [MF], Manual Focus (MF) is enabled.
6
Lens fitting mark
7
Contact points
8
Lens mount rubber
Note
• When recording on the wide-angle side and using the
flash, the periphery of the screen may darken. In such
cases, we recommend using the external flash.
• If you zoom after focusing, focusing errors may occur.
After zooming, please perform the focusing again.
• In very quiet situations Auto Focus operating sounds
may be recorded during motion picture recording. This is
not a malfunction. In such situations, switching to
Manual Focus will improve the situation.
• If you set the O.I.S. to [ON] when recording a motion
picture, operating sounds may be recorded. If they
become bothersome, we recommend setting the O.I.S.
switch to [OFF] and mounting the camera on a tripod.
D

Attaching/Detaching the Lens

For information on how to attach and remove the lens,
refer to the owner's manual for your digital camera.
• Before attaching or detaching the lens, check that
the digital camera is turned off.
• Before attaching the lens to the digital camera, remove
the lens rear cap A by rotating it in the direction of the
arrow.(See illustration
• To prevent dust and other particles from accumulating on
or entering the lens, be sure to attach the lens cap/lens
rear cap after detaching the lens from the digital camera.
∫
Attaching Filters
• Vignetting may occur if using 2 or more filters at the same time.
• It is possible to attach the lens cap with the filter already attached.
• When using the lens hood and a filter at the same time,
attach the filter first.
• You cannot attach a conversion lens or adaptor to this
lens. A filter may be used, but attaching any other
element may cause damage to the lens.
∫
Attaching the Lens Hood (Supplied Accessory)
(See illustration
Hold the lens hood with your fingers placed as shown
in the picture ( B ).
• Do not hold the lens hood in a way that twists or bends it. ( C )
)
)
/ )
