Sullivan-Palatek D210UHJD4PTOW User Manual

Utility compressor / pto auxiliary drive / 210 cfm, john deere diesel engine tier 4 final
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
UTILITY COMPRESSOR \ PTO AUXILIARY DRIVE \ 210 CFM
D210UHJD4PTOW
JOHN DEERE DIESEL ENGINE
TIER 4 FINAL
05018730 0238 / 00
Issued: January 23, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D210UHJD4PTOW and is the answer not in the manual?

Questions and answers

Related Manuals for Sullivan-Palatek D210UHJD4PTOW

Summary of Contents for Sullivan-Palatek D210UHJD4PTOW

  • Page 1 USER MANUAL UTILITY COMPRESSOR \ PTO AUXILIARY DRIVE \ 210 CFM D210UHJD4PTOW JOHN DEERE DIESEL ENGINE TIER 4 FINAL 05018730 0238 / 00 Issued: January 23, 2018...
  • Page 2 DOCUMENT INFORMATION © Sullivan-Palatek, Inc. ALL RIGHTS RESERVED Part Number: 05018730 0238 Revision: 00 CONTACT INFORMATION Sullivan-Palatek, Inc. 1201 West US Highway 20 Michigan City, Indiana 46360 Phone: (219) 874-2497 Fax: (219) 872-5043 Toll Free: (800) 438-6203 Website: www.sullivan-palatek.com RECORD KEEPING...

  • Page 3: Standard Warranty

    Palatek or 12 months from delivery to the first user. Parts, accessories and attachments sold separately from machines, excluding warranty replacement parts and hand tools: the first to expire; 6 months from shipment by Sullivan-Palatek or 3 months from delivery to the first user.

  • Page 5: About This Manual

    MANUAL ORGANIZATION NOTE! Anyone operating or servicing the Sullivan-Palatek air compressor should read this entire manual and be familiar with its information. The following is a quick guide to the contents in this manual: SECTION 1: SAFETY This section contains important basic information regarding general safety precautions for maintaining and operating air compressors.
  • Page 6 AbouT ThIS MANuAl...

  • Page 7: Table Of Contents

    Engine Regeneration Process ..............28 Sullivan-Palatek Electronic Controller (SPEC) operating Instructions .......30 4.10...
  • Page 8 WEAThER-All Compressor Lubricant............40 ™...

  • Page 9: Safety

    SAFETY TOPICS IN THIS SECTION: » General Safety ................2 »...

  • Page 10: General Safety

    GENERAL SAFETY Safety is a prime consideration in the design and manufacture of the compressor. ultimately, the responsibility for safe operation rests with the individuals who use and maintain the compressor. The following safety precautions are offered as a guide for the safe operation and maintenance of this machinery: »...

  • Page 11: Moving Parts

    » Anti-freeze compound used in airline anti-icing systems contains methanol, which is flammable. use systems and refill with compound only in well-ventilated areas, away from heat, open flames, or sparks. Do not expose any part of these systems or the anti-freeze compound to temperatures above 150°F (65°C).

  • Page 12: Toxic And Irritating Substances

    Under specific guidelines and in full compliance with OSHA Standards 29 CFR 1920 and any other federal, state, or local codes or regulations compressed air can be used for breathing air. Sullivan-Palatek does not provide equipment and instructions for this application and its products are not produced for this application or use.

  • Page 13: Hot Surfaces, Sharp Edges, Sharp Corners And Vacuum

    HOT SURFACES, SHARP EDGES, SHARP CORNERS AND VACUUM » Avoid contact with hot oil, hot coolant, hot surfaces, and sharp edges and corners. » Keep all parts of the body away from all points of air discharge and away from hot exhaust gases. »...
  • Page 14 SaFETy...

  • Page 15: Specifications

    SPECIFICATIONS TOPICS IN THIS SECTION: » Technical Data................8 »...

  • Page 16: Technical Data

    TECHNICAL DATA D210UHJD4PTOW COMPRESSOR Type Single Stage, Oil Flooded Rotary Screw Rated Delivery 210 cfm (5.0 m3/min) Rated Operating Pressure 100 psig (6.9 bar) LOW 150 psig (10.4 bar) HIGH Rated Operating Pressure Range 70–165 psig (4.9–11.3 bar) Ambient Temperature Range -20 to +125°F (-29 to +52°C)

  • Page 17: Dimensional Drawing

    DIMENSIONAL DRAWING FIgUrE 2-1. GA 00006 (REV 00) SPECIFICATIoNS...

  • Page 18: Wiring Diagram

    WIRING DIAGRAM FIgUrE 2-2. WD-15115 (REV 01) SPECIFICATIoNS...

  • Page 19: Schematic Diagram

    SCHEMATIC DIAGRAM FIgUrE 2-3. SD-1002 (REV 01) SPECIFICATIoNS...

  • Page 20: Engine-Ecu Harness

    ENGINE-ECU HARNESS STARTER SOLENOID (NOT IN HARNESS) FIgUrE 2-4. 05018395 0247 (REV 04) SPECIFICATIoNS...

  • Page 21: Starter Grounds Harness

    STARTER GROUNDS HARNESS FIgUrE 2-5. 05018395 0253 (REV 01) SPECIFICATIoNS...

  • Page 22: Pto Sae 'A' Drive

    PTO SAE ‘A’ DRIVE FIgUrE 2-6. PoWER TAkE-off AuxiliARy DRiVE SPEcS SPECIFICATIoNS...

  • Page 23: Component Description

    COMPONENT DESCRIPTION TOPICS IN THIS SECTION: » Portable Compressor Package ..............16 »...

  • Page 24: Portable Compressor Package

    PORTABLE COMPRESSOR PACKAGE The compressor is a single stage, oil-flooded lubricated rotary screw air compressor. The compressor package is available as a portable wheel-mounted unit, utility mounted unit, or galvanized skid-mounted unit for offshore applications. All models are enclosed in a weather-resistant acoustical enclosure. The complete operating unit consists of a diesel engine for power, compressor assembly, air/oil separator system, cooling system for the engine and compressor oil, instrumentation, pneumatic control system, and acoustical enclosure.

  • Page 25: Lubrication System

    LUBRICATION SYSTEM FIgUrE 3-2. DiAGRAM, oil PiPiNG 185-375 (REV 00) Oil from the compressor oil sump at compressor discharge pressure is directed through the cooling system and oil filter to a lower pressure region of the compressor stator. At the same time, oil is directed to the bearings and shaft seal of the compressor.

  • Page 26: Oil Filter

    The engine speed is regulated by a pressure transducer signal through the CANBUS and the Sullivan-Palatek Electronic Controller (SPEC). From full to approximately 60% capacity, the delivery is controlled by engine speed and a gradual closing of the inlet valve. When unloaded the inlet valve is closed to prevent atmospheric air from entering the compressor.

  • Page 27: Electrical And Protective Circuit System

    ENGINE SHUTDOWN PROTECTION Sullivan-Palatek uses electronically controlled engines in the 185–1800 CFM line of compressors. Personnel operating and maintaining these compressors MUST be familiar with and understand the operation and protection features available with these engines.

  • Page 28: Power Take-Off (Pto) Drive

    NOTE! The Sullivan-Palatek warranty DOES NOT COVER the engine. The engine and its components are warranted only by the engine manufacturer. Operators, rental customers and anyone responsible for the operation and maintenance of this compressor MuST be instructed and briefed on the proper responses to control module warnings.

  • Page 29: Instrument Panel

    INSTRUMENT PANEL, DUAL PSI ITEM NAME DESCRIPTION Discharge Air Pressure Gauge Displays discharge air pressure of compressor. Sullivan-Palatek Electronic Monitors the engine and compressor parameters, displays warning and Controller (SPEC) shutdown information, and displays engine diagnostic information from the engine ECU. Ignition Switch START position electrically energizes engine starter motor solenoid.

  • Page 30: Ignition Switch

    3.11.2 SULLIVAN-PALATEK ELECTrONIC CONTrOLLEr (SPEC) MODEL PV480 The Sullivan-Palatek Electronic Controller (SPEC) Model PV480 monitors all critical compressor and engine parameters, provides warning and shutdown information and has complete engine diagnostic capabilities. Parameters monitored by the SPEC include engine speed, compressor temperature, engine oil pressure, engine temperature, battery voltage and fuel level.

  • Page 31: Optional Equipment

    (PTO) Drive on page 20 for clarification and PTO auxiliary drive Factory authorization. 3.12 OPTIONAL EQUIPMENT Sullivan-Palatek offers an extensive variety of options on all portable and utility products. Multiple options are available for each of the sub-categories listed below. Please consult Sullivan-Palatek Sales for more information.
  • Page 32 CoMPoNENT DESCRIPTIoN...
  • Page 33 Engine Regeneration Process..............28 » Sullivan-Palatek Electronic Controller (SPEC) Operating Instructions.......30 »...

  • Page 34: Installation & Operation

    RECEIVING Each compressor is operated and tested at the factory before shipment. This testing assures that the unit is operating properly and that the compressor will deliver its rated capacity. Regardless of the care taken at the factory, there is a possibility that adjustments may be altered or damage may occur during shipment. For this reason it is recommended that the unit be checked for proper operation and carefully inspected before it is put in service.

  • Page 35: Normal Starting

    Fill the fuel tank with fuel recommended in the Engine Manual. WARNING! Never add gasoline to diesel fuel tank - serious damage to the engine will result. If necessary, add lubricating oil to the compressor sump. Refer to 5.3 Compressor Lubrication on page 39 for lubricating oil specifications.

  • Page 36: Engine Regeneration Process

    The exhaust filter cleaning can only be skipped/disabled twice, and then a manual or parked Regeneration must be performed. The compressor is factory set with active automatic Regeneration. To perform a manual or parked Regeneration, refer to 4.9 Sullivan-Palatek Electronic Controller (SPEC) Operating Instructions on page 30 for instructions. INSTAllATIoN AND oPERATIoN...
  • Page 37 WARNING! Always take precautions while performing either type of Regeneration, as hotter exhaust temperatures may cause a fire or similarly dangerous situation. Refer to the engine manual for proper safety procedures. When an automatic or manual Regeneration is in process, Regeneration icons are shown on the digital display.

  • Page 38: Sullivan-Palatek Electronic Controller (Spec) Operating Instructions

    SULLIVAN-PALATEK ELECTRONIC CONTROLLER (SPEC) OPERATING INSTRUCTIONS The buttons for operation will be referred to numerically based upon the image at right. Button functionality can vary depending on the operator input required for each page. Pages requiring custom button functionality will display button function icons directly above the buttons.
  • Page 39 USER SETTINGS MENU user display settings are located here. button 1 cycles through the list of selections; button 3 returns back to the home Page; button 4 switches between day and night mode (min and max contrast); button 5 saves the settings. Ambient Light: switches between day and light mode;...
  • Page 40 INTERLOCK ON/OFF 4.) Setting the Interlock to oN, the user must return to the EXhAuST FIlTER STATuS MENu and move down to Request Exh Filter Clean option and a Regeneration will begin. UTILITIES MENU buttons 1 and 2 cycle through the list of selections; button 3 returns back to the home Page;...

  • Page 41: Operating Under Extreme Conditions

    DATE AND TIME button 1 moves the selections up and down; buttons 2 and 4 increment the selection up or down; button 3 returns back to the home page; button 5 saves and confirms the settings. DIAGNOSTICS MESSAGE POP-UP Fault codes will generate a pop-up message on screen.

  • Page 42: Pneumatic Tools Application

    WARNING! Check the compressor sump oil level only when the compressor is not operating and system is completely relieved of pressure. Open pressure relief valve to ensure relief of system air pressure when performing maintenance on compressor air/oil system. Failure to comply with this warning may cause property damage and serious bodily harm or death. 4.11 PNEUMATIC TOOLS APPLICATION WARNING!

  • Page 43: Jump-Starting Battery

    4.12 JUMP-STARTING BATTERY WARNING! Always wear an acid-resistant apron, face shield with goggles and gloves when working with batteries! WARNING! Batteries may contain hydrogen gas which is explosive and flammable! Keep flames, sparks and any other source of ignition away. Batteries also contain acid which is corrosive and poisonous. DO NOT allow battery acid to contact eyes, skin, or fabrics.
  • Page 44 INSTAllATIoN AND oPERATIoN...

  • Page 45: Maintenance

    MAINTENANCE TOPICS IN THIS SECTION: » Maintenance Schedule ...............38 »...

  • Page 46: Maintenance Schedule

    MAINTENANCE SCHEDULE COMPRESSOR MAINTENANCE SCHEDULE FREQUENCY (HOURS) PROCEDURE SEE NOTE REF� Check oil level (before starting) Check radiator coolant level check fuel supply (after starting) check air filter elements Check for fuel, oil air and water leaks Drain water from compressor sump Drain water and sediment from fuel tank change oil filter element Change compressor oil...

  • Page 47: Bolt Torque Guidelines

    When ambient conditions exceed those noted, or if conditions warrant use of “extended life” lubricants, contact Sullivan-Palatek for a recommendation. 5.3.1 CHECK The oil level should be checked daily.

  • Page 48: Weather-All ™ Compressor Lubricant

    For this reason an hourly service on lubricants is merely a guide. Please consult your factory-trained servicing distributor for questions concerning your lubricant life and Sullivan-Palatek’s lubricant sampling program. See 5.5 Oil Sample for Analysis for additional information.

  • Page 49: Oil Sample For Analysis

    OIL SAMPLE FOR ANALYSIS The first oil sample should be drawn after the compressor has run for 500 hours or 3 months. Intervals for following oil samples will be determined by the analysis results. SAMPLE OIL FROM SUMP TANK Run the compressor long enough to reach normal operating temperatures. Turn compressor oFF and allow pressure to blow down to 0 psi.

  • Page 50: Curbside Service Access

    CURBSIDE SERVICE ACCESS all maintenance points, drains, and the SPEC controller display are conveniently located behind the curbside access door. Fuel fill and serviceable parts such as filters can be accessed from this location. ENGINE AIR FILTER FUEL FILL FUEL/WATER SEPARATOR EXTENDED DIPSTICK COMPRESSOR OIL FILTER COMPRESSOR AIR FILTER...

  • Page 51: Installation

    5.10.1 REMOVAL AND INSPECTION unscrew wingnut to remove air filter cover. Remove and inspect the used primary element by turning counter-clockwise to unscrew.Unscrew air filter wingnut and pull used primary element to remove. The air filter elements should be thoroughly inspected for holes by placing a lamp inside the element and carefully checking for areas of bright light passing through the element and seal.

  • Page 52: Thermal Valve

    5.16.2 ENGINE SPEED Engine speed is controlled by the Sullivan-Palatek Electronic Controller (SPEC). The full load and idle speeds are programmed at the factory and there should be no need for adjustment. If the machine is experiencing speed problems please contact our Service Department.

  • Page 53: Troubleshooting

    TROUbLESHOOTING TOPICS IN THIS SECTION: » Introduction................46 »...

  • Page 54: Introduction

    INTRODUCTION This section contains instructions for troubleshooting the equipment following a malfunction. Each issue or problem is followed by a list of probable causes and suggested actions to be followed in order to eliminate the cause. The actions listed should be performed in the order listed, although the order may be varied if the need is indicated by conditions under which the problem occurred.

  • Page 55: Discharge Pressure Is Too High Or Relief Valve Blows

    DISCHARGE PRESSURE IS TOO HIGH OR RELIEF VALVE BLOWS POSSIbLE CAUSE ACTION Regulator valve faulty or mis-adjusted Properly adjust the regulator. Rebuild/replace the regulator if necessary. Inlet valve not closing properly Check the white sealing ring for the poppet valve, to ensure it is intact and not damaged.

  • Page 56: Engine Does Not Accelerate Or Will Not Maintain Full Load Speed

    ENGINE DOES NOT ACCELERATE OR WILL NOT MAINTAIN FULL LOAD SPEED POSSIbLE CAUSE ACTION Compressor discharge pressure too high Adjust the pressure to the maximum operating pressure for the machine. Engine problem Have an authorized engine repair facility inspect the engine.

  • Page 57: Compressor Oil Leaking In Control Lines/Orifices

    6.13 COMPRESSOR OIL LEAKING IN CONTROL LINES/ORIFICES POSSIbLE CAUSE ACTION Compressor oil level in sump tank too full Check and adjust compressor oil as needed. Oil return line (scavenger tube) plugged or restricted Remove the oil return line and clean. Separator element plugged or damaged Replace the separator element and change compressor oil.
  • Page 58 TRoublEShooTING...

  • Page 59: Parts Catalog

    PARTS CATALOG TOPICS IN THIS SECTION: » Ordering Parts................52 »...

  • Page 60: Ordering Parts

    Use the space provided on the inside cover of the manual to record the model and serial number of the compressor for future reference. 7.1.1 CONTACT INFORMATION For replacement parts and manuals contact: Sullivan-Palatek, Inc. 1201 West US Highway 20 Michigan City, Indiana 46360 Phone: (219) 874-2497 Fax: (219) 872-5043 Toll Free: (800) 438-6203 www.sullivan-palatek.com...

  • Page 61: Recommended Spare Parts

    00823062 0010 FLUID, COMPRESSOR WEATHER-ALL (55 GALLON) NOTE! Use only service parts supplied or recommended by Sullivan-Palatek. Use of substitutes may void warranty. See STANDARD WARRANTY for details. SERVICE KITS Service kits are available for basic servicing of the compressor and engine. buying kits offers savings over buying individual parts.

  • Page 62: Engine Assembly

    ENGINE ASSEMBLY FIgUrE 8-1. 00717585 0301 (REV 01) PARTS CATAloG...
  • Page 63 PARTS CATAloG...
  • Page 64 ENGINE ASSEMBLY (CONTINUED) FIgUrE 8-2. 00717585 0301 (REV 01) PARTS CATAloG...
  • Page 65 PARTS CATAloG...
  • Page 66 ENGINE ASSEMBLY (CONTINUED) FIgUrE 8-3. 00717585 0301 (REV 01) PARTS CATAloG...
  • Page 67 PARTS CATAloG...

  • Page 68: Battery Assembly

    RELEASED FOR PR 18 ZINC PLATED REDRAWN. 03903040 00 5/16-18 X 10.00 BATTERY ASSEMBLY REDRAWN IN SO RY HOLD DOWN ARD 800CCA UNLESS OTHERWISE NOT DIMENSIONS ARE IN INCH TOLERANCES AS FOLLOW ANGLES: + OR - 1/2 DEG. DECIMAL: X.X + OR - 0.05 X.XX + OR - 0.02 X.XXX + OR - 0.0 MATERIAL:...
  • Page 69 00717820 0050 bATTERY ASSEMbLY ITEM PART NUMbER DESCRIPTION 00900321 0003 WASHER, FLAT .3125 ZINC PLATED 00903192 0003 NUT, WING .3125-18 ZINC PLATED 00910106 0230 THREADED RoD, 5/16-18 x 10.00 03903040 0022 BRAckET, BATTERy HolD DoWN 05017195 0004 BATTERy, STANDARD 800ccA PARTS CATAloG...

  • Page 70: Exhaust Assembly

    EXHAUST ASSEMBLY FIgUrE 8-5. 00717796 0161 (REV 01) PARTS CATAloG...
  • Page 71 PARTS CATAloG...

  • Page 72: Compressor Assembly

    SHEET THIS DRAWING AND ALL INFORMATION THEREIN IS THE PROPERTY OF SULLIVAN-PALATEK, INC. IS CONFIDENTIAL AND MUST NOT BE MADE PUBLIC OR COPIED. IT IS LOANED SUBJECT TO RETURN UPON DEMAND, IS NOT TO BE USED DIRECTLY OR INDIRECTLY IN ANYWAY DETRIMENTAL TO SULLIVAN-PALATEK'S INTEREST.
  • Page 73 ScREW, HEx HD M10-1.5 x 35MM GR 8.8 ZN PlT KB09147-362 SHAFT SEAL KIT, 3LIP, CW (NOT SHOWN) 00910751 0810 ADAPTER, ElBoW 90° 3/4MoRBx5/8Jic *When contacting Sullivan-Palatek about a replacement air end, please have compressor serial number and local Dealer information available. PARTS CATAloG...

  • Page 74: Inlet Valve Assembly

    DESCRIPTION BOLT, WHIZ GR5 1/2 -13 X 1 ELBOW, ORIFICE .030 BRASS 1/4 STREET ELBOW, .38 TUBE X .25 MNPT BRASS 7.10 INLET VALVE ASSEMBLY NIPPLE, HEX PIPE 1/4 X 1/4 O-RING, 3.5 ID X 3.75 OD SENDER, PRESSURE 0-200PSI TEE, PIPE .25NPT #150 GLV TEE, MALE RUN 1/4 MNPT X 3/8 TUBE BRASS VALVE, ASY INLET 2.5"...
  • Page 75 00717985 0049 INLET VALVE ASSEMbLY ITEM PART NUMbER DESCRIPTION 93115-014 BolT, WHiZ GR5 1/2 -13 x 1 01900592 0042 ELBOW, ORIFICE .030 BRASS 1/4 STREET 00915557 0064 ElBoW, .38 TuBE x .25 MNPT BRASS 00906058 0004 NiPPlE, HEx PiPE 1/4 x 1/4 00907864 0238 o-RiNG, 3.5 iD x 3.75 oD 05019205 0007...

  • Page 76: Air Filter Assembly

    7.11 AIR FILTER ASSEMBLY FIgUrE 8-8. 00717642 0194 (REV 02) PARTS CATAloG...
  • Page 77 PARTS CATAloG...
  • Page 78 AIR FILTER ASSEMBLY (CONTINUED) AIR FILTER REPLACEMENT PARTS ITEM # PART NUMBER DESCRIPTION QTY. ITEM # PART NUMBER DESCRIPTION 00077-353 SLEEVE, HOSE HUMP 3.5 X 3.0 18174-088C FILTER HOUSING 00131-082 BAND, MTG 8IN PLSTC 00521-082 ELEMENT, PRIMARY 00900321 0003 WASHER, FLAT .3125 ZINC PLATED 00521-082S ELEMENT, SECONDARY 00900389 0002...
  • Page 79 00717642 0194 AIR FILTER ASSEMbLY ITEM PART NUMbER DESCRIPTION 00077-353 SlEEVE, HoSE HuMP 3.5 x 3.0 00131-082 BAND, MTG 8IN PLSTC 00900321 0003 WASHER, FLAT .3125 ZINC PLATED 00900389 0002 BolT, BuTToN HEAD .25-20 x .75 ZN PlT 00900490 0062 NuT, Nylok 5/16-18 ZiNc PlATED 00902319 0014 CLAMP, HOSE 2.9875 TO 3.750...

  • Page 80: Receiver Assembly, Dual Pressure

    7.12 RECEIVER ASSEMBLY, DUAL PRESSURE FIgUrE 8-10. 00717884 0220 (REV 01) PARTS CATAloG...
  • Page 81 PARTS CATAloG...
  • Page 82 RECEIVER ASSEMBLY, DUAL PRESSURE (CONTINUED) FIgUrE 8-11. 00717884 0220 (REV 01) PARTS CATAloG...
  • Page 83 PARTS CATAloG...
  • Page 84 RECEIVER ASSEMBLY, DUAL PRESSURE (CONTINUED) FIgUrE 8-12. 00717884 0220 (REV 01) PARTS CATAloG...
  • Page 85 PARTS CATAloG...

  • Page 86: Air Out Receiver Assembly

    SHEET THIS DRAWING AND ALL INFORMATION THEREIN IS THE PROPERTY OF SULLIVAN-PALATEK, INC. IS CONFIDENTIAL AND MUST NOT BE MADE PUBLIC OR COPIED. IT IS LOANED SUBJECT TO RETURN UPON DEMAND, IS NOT TO BE USED DIRECTLY OR INDIRECTLY IN ANYWAY DETRIMENTAL TO SULLIVAN-PALATEK'S INTEREST.
  • Page 87 00717885 0009 AIR OUT RECEIVER ASSEMbLY ITEM PART NUMbER DESCRIPTION 00900115 0083 BolT, 3/8-16 x 2-3/4 HHcS GR5 00900490 0081 NuT, Nyloc 3/8-16 ZiNc PlATED 00901135 0005 UNION, PIPE 1.0 FNPT 150# GLV 00901161 0017 BuSHiNG, PiPE 1-1/4 NPT x 1.0NPT 150# GlV 00901177 0060 NiPPlE, PiPE 1.00 x 2.00 ScH 80 GAlV 00901177 0066...

  • Page 88: Discharge Hose Assembly

    7.14 DISCHARGE HOSE ASSEMBLY FIgUrE 8-14. 00717886 0008 (REV 02) PARTS CATAloG...
  • Page 89 PARTS CATAloG...

  • Page 90: Control Tubing

    7.15 CONTROL TUBING FIgUrE 8-15. cD 00026 (REV 00) PARTS CATAloG...
  • Page 91 PARTS CATAloG...

  • Page 92: Cooling Assembly

    7.16 COOLING ASSEMBLY FIgUrE 8-16. 00717532 0224 (REV 01) PARTS CATAloG...
  • Page 93 PARTS CATAloG...
  • Page 94 COOLING ASSEMBLY (CONTINUED) FIgUrE 8-17. 00717532 0224 (REV 01) PARTS CATAloG...
  • Page 95 PARTS CATAloG...

  • Page 96: Oil Filter And Piping

    7.17 OIL FILTER AND PIPING FIgUrE 8-18. 00717620 0100 (REV 01) PARTS CATAloG...
  • Page 97 PARTS CATAloG...
  • Page 98 OIL FILTER AND PIPING (CONTINUED) FIgUrE 8-19. 00717620 0100 (REV 01) PARTS CATAloG...
  • Page 99 PARTS CATAloG...

  • Page 100: Fuel Tank Assembly

    7.18 FUEL TANK ASSEMBLY FIgUrE 8-20. 00717972 0133 (REV 01) PARTS CATAloG...
  • Page 101 PARTS CATAloG...
  • Page 102 FUEL TANK ASSEMBLY (CONTINUED) FIgUrE 8-21. 00717972 0133 (REV 01) PARTS CATAloG...
  • Page 103 PARTS CATAloG...

  • Page 104: Instrument Panel Assembly

    7.19 INSTRUMENT PANEL ASSEMBLY FIgUrE 8-22. 00717680 0179 (REV 00) PARTS CATAloG...
  • Page 105 PARTS CATAloG...
  • Page 106 INSTRUMENT PANEL ASSEMBLY (CONTINUED) FIgUrE 8-23. 05018845 0174 (REV 00) PARTS CATAloG...
  • Page 107 PARTS CATAloG...

  • Page 108: Enclosure Assembly

    7.20 ENCLOSURE ASSEMBLY FIgUrE 8-24. 00717598 0138W (REV 02) PARTS CATAloG...
  • Page 109 PARTS CATAloG...
  • Page 110 ENCLOSURE ASSEMBLY (CONTINUED) FIgUrE 8-25. 00717598 0138W (REV 02) PARTS CATAloG...
  • Page 111 PARTS CATAloG...
  • Page 112 ENCLOSURE ASSEMBLY (CONTINUED) FIgUrE 8-26. 00717598 0138W (REV 02) PARTS CATAloG...
  • Page 113 PARTS CATAloG...
  • Page 114 ENCLOSURE ASSEMBLY (CONTINUED) FIgUrE 8-27. 00717598 0138W (REV 02) PARTS CATAloG...
  • Page 115 PARTS CATAloG...
  • Page 116 ENCLOSURE ASSEMBLY (CONTINUED) FIgUrE 8-28. 00717598 0138W (REV 02) PARTS CATAloG...
  • Page 117 PARTS CATAloG...

  • Page 118: Machine Dress

    7.21 MACHINE DRESS FIgUrE 8-29. 00717752 0336 (REV 01) PARTS CATAloG...
  • Page 119 PARTS CATAloG...
  • Page 120 MACHINE DRESS (CONTINUED) FIgUrE 8-30. 00717752 0336 (REV 01) PARTS CATAloG...
  • Page 121 PARTS CATAloG...

  • Page 122: Acoustics Assembly

    7.22 ACOUSTICS ASSEMBLY FIgUrE 8-31. 00717100 0023 (REV 00) PARTS CATAloG...
  • Page 123 PARTS CATAloG...

  • Page 124: Frame Assembly

    7.23 FRAME ASSEMBLY FIgUrE 8-32. 00717464 0120 (REV 00) PARTS CATAloG...
  • Page 125 PARTS CATAloG...
  • Page 126 NOTES...
  • Page 127 NOTES...
  • Page 128 1201 Wes t US Highway 20 Michigan Cit y, Indiana 46360 Phone: 219.874.2497 Fax: 219.809.0203 info@palatek .com w w w.sullivan-palatek .com...
