AUSTRALIAN MONITOR AMIS MCS1 Introduction

Microphone Splitter/Combiner
Introduction
The Australian Monitor Installation Series MCS1 mic splitter/combiner
produces 2 balanced XLR signals, (1 direct, 1 transformer isolated) from a
single balanced XLR input. The AMIS MCS1 provides a ground lift switch to
eliminate hum, & as part of the AMIS Contractor Tools range, the AMIS
MCS1 is an inexpensive splitter/combiner that has a multitude of uses in a
wide variety of installations.

Description

• Input: This balanced XLR input receives signal from a mic or other
source.
• Thru Output: This balanced XLR output is wired in parallel to the Input
& provides a balanced signal output.
• Output: This XLR output provides a transformer isolated output of the
input signal feed.
• GND Lift Switch: When this switch is in "ground" position pin1 of both
the input & the output are connected. When this switch is in "lift"
position these grounds are separated. This switch is used to
eliminate hum.

Specifications

Input impedance:
Output Impedance:
Dimensions:
Weight:
AMISMCS1
600 Ohms
600 Ohms
95mm x 73mm x 40mm
305.5g
