Installing a Power Supply
Figure 3: 715W DC Power Supply (PWR-C1-715WDC)
1
715 W DC power supply module
2
DC OK LED
3
PS OK LED
4
Release latch
5
Extraction handle
If no power supply is installed in a power supply slot, install a power supply slot cover.
Power Supply Modules Overview
6
Input power terminal (positive polarity)
7
Input power terminal (negative polarity)
8
Grounding terminal
9
Terminal block safety cover
-
-
Installing a Power Supply
5
