PROBLEM
Unit fails to boil
Accessories fall off
Water spitting out
Loud buzzing noise No water in the tank
from inside the
Steam Unit
Steam being
emitted from
emergency vent at
the back of the
Water Tank
The following spare parts are available from Earlex Inc. Please contact our helpline TOLL FREE
800 252 1288 to place your order.
SPARE PART NO.
M0001
M0050
M0075
M0090
M0110
M0290
M0295
M0310
M0530
M0580
M0605
M0610
M0611
M0615
M0616
M0625
HELPLINE NUMBER - TOLL FREE 888 STEAM 12. CALL FIRST IF YOU HAVE ANY PROBLEM

TROUBLE SHOOTING

CAUSE
Not switched on
Fuse has blown
Not properly fitted
Too much water in tank
Initial ejection at warm up Press steam release button for initial
Not heated up
Pressure relief valve is
operating due to blockage Allow the unit to cool for at least 5 minutes.
of steam
SPARE PARTS & ACCESSORIES
SPARE PART DESCRIPTION
Floor Cleaner
Upholstery Cleaner/Garment Steamer
Garment Attachment Rest
Window/Tile Cleaner
Extension Tubes
Jet Nozzle
Scraper Nozzle
Water Tank Lid
Water Tank
Brush Nozzle
Brush Nozzle kit, different colours (3 pieces)
Upholstery Cleaner/Garment Steamer Bonnet (3 pieces) 32
Floor Cleaner Bonnet (3 pieces)
"O" Ring set for Water Tank
"O" Ring set for Nozzle Connection (6 pieces)
Brush Nozzle with wire bristles (2 pieces)
ACTION
Check that the mains is switched on and the
ON/OFF switch on the unit has also been
operated - Push button will illuminate.
Check fuse in any Extension Cable that is in use.
Review fitting instructions.See page 8.
Reduce the water level.
discharge until steam is produced. See page 13.
Wait for Steam Ready neon Indicator to light.
Refill the Water Tank.
Switch off the unit.
Check all steam holes in the Attachment, and the
Nozzle Connections in the Handle and Extension
Tubes being used, to ensure there is no debris or
lime-scale preventing steam from passing
through them and clean out accordingly.
The build up of lime-scale can be avoided by
always using cooled, boiled water when filling
the Water Tank.
15
REF NO ON P. 7
27
29
30
28
25
14
15
7
8
16
N/A
31
N/A
N/A
N/A
