Samsung SMT-3211 Specifications

SMT -3211
32" Large Format LCD Display
Dimensions (unit : in)
Front/Rear Panel
7.87
Summary
The SMT-3211 large format monitor provides Multi Display Control (MDC)
function that allows you to control up to 10 units from your PC with the
supplied MDC software.
The Built-in Video Wall Image Enlarging Processor supports 2 x 2, 3 x 3, 4
x 4, 5 x 1 and 1 x 5 video walls without the need of requiring any separate
video controller device. No additional input signal distribution is necessary
to use the video and PC interface.
The 2-Way Video Wall Display in "Full" mode displays the picture regardless
of cabinet bezel and in "Natural" mode considers the bezel's depth and
adjusts for a properly proportioned picture.
Features
• Anti Image Burn/Pixel Cleansing
• Extended Video Wall Format
• Picture in Picture(PIP) and Picture by Picture(PBP)
• Superior Images Quality
• Wide Angle Viewing
• 8ms Response Time
• 24/7 Operation with Built in Power Supply
• Multiple Inputs: D-Sub, RS232C cable, DVI-D, USB 2.0, S-Video, CVBS
Video, BNC
• VESA Wall Mount Standard
30.7 4.21
8.77
SAMSUNG | GVI Security • Toll Free: 888-595-2288 • Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice • v2.6.09
Matrix Display for Video Wall
Built-in image enlarging that supports 2x2, 3x3, 4x4, 5x5, 1x2, 2x1, 1x5, 5x1 video
walls. You don't need any video controller device. To use video and PC interface,
an additional input signal distributor is not necessary either.
5x5 5x1
Multiple Connections
Many monitors have limited feature sets and lack the versatility to connect to
the video devices in a system. SAMSUNG Electronics LCD Displays provide
multiple video formats such as D-Sub, RS232C Cable, DVI-D, USB 2.0, S-Video,
CVBS Video, BNC that may be missing from a lower cost monitor.

Specifications

Picture Screen Size
Resolution
Brightness (cd/m2)
Panel Contrast
Response Time
Viewing Angle Degree
Picture Color Supported
Video Signal Analog RGB, DVI-D, Composite S-Video, Component Video
Sync. Signal Separate H/V, Composite, SOG
Connector D-Sub, RS232C Cable, DVI-D, USB 2.0, S-Video, CVBS
Video, BNC
Power Power Consumption
Stand By Power (DPMS)
Type Internal
Plug & Play DDC 2B
Multimedia Speakers 10Wx2ch (Option)
Special Features Anti-image retention, Matrix Video Wall (2x2, 3x3, 4x4,1x5,
5x1, 5x5), Safety Lock, PIP / PBP , VESA Wall Mount Stan-
dard, Signal Balance, Vertical Input, External AV Devices
PC Compatibility Windows/Mac
Wall-Mount Mounting Kit Available (Option)
Cabinet Color Black
Accessories MDC Programme, User Manual, Tablefoot 2 pcs, RCA RCA
Adapter 4 pcs, Power Cable, Remote controller
Physical Specification Product Weight
Shipment Weight
Product Dimension (WxHxD) (W/ Stand) 30.7 x 20.8 x 8.8 in
Shipment Dimension
Enviornmental Conditions Operating Temperature
Stand (Type) Foot Stand
3x3 1x5
32"
1366 x 768 pixels, 500TV Lines
410cd/m²
1,000:1
8msec(GTG)
(Horz/Vert) 178˚/178˚
16.7 Mil
160 Watts @ 120 VAC
<1 Watts
16.1kg / 35.4 lbs
21.4kg / 47.0 lbs
/ 780 x 530 x 223 mm
(W/Out Stand) 30.7 x 18.9 x
4.2 in / 780 x 482 x 107 mm
35.3 x 23.6 x 10.3 in / 898 x
600 x 262 mm
50º ~ 104ºF(10º ~ 40ºC)
GVI Security
