BenQ 3D Glasses 2 User Manual

3D Glasses User Manual

COMPLIaNCE INFORMaTION

For U.S.A.
This device complies with part 15 of FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation. This equipment has been
tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your authority
to operate the equipment.
For Canada
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low
Voltage Directive 2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment
as unsorted municipal waste, but use the return and collection systems
according to local law.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery has
a heavy metal content of more than 0.0005% Mercury or more than, 0.002%
Cadmium, or more than 0.004% Lead.

3D VIEWING GUIDELINES

• If the projector becomes disconnected due to either a change in the
viewing angle or distance, the 3D glasses turn off automatically after 30
seconds.
• The 3D glasses may not work properly if there is any other 3D product
or electronic devices turned on near the glasses or projector.
• Be sure to stay within the viewing angle and optimum viewing distance
when watching 3D pictures. Otherwise, you may not be able to enjoy
proper 3D effects.
BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618
BenQ is a registered trademark of BenQ Corp. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.

PaRT NaMES

aCCESSORIES

SYSTEM REqUIREMENTS

The 3D glasses are designed to be emitter free and work with 3D enabled
DLP ® Link projectors. The DLP projector should be in 3D mode and
displaying 3D content

BENEFITS

• Light weight design for comfortable long-time wear
• Long effective distance (up to 12 meters) when used in conjunction with
a projector which has a brightness output of more than 2000 lumens.
• Good resistance against ambient light interference.

USING 3D GLaSSES

• Power On
– Press the power button once. The red LED blinks 10 times quickly.
• Power Off
– Press the power button. The red LED blinks 5 times.
• auto Off
– The power is automatically turned off if no signal is transmitted for
30 seconds.
• Free Run
– The 3D glasses work for 10 seconds in no signal.

BaTTERY INDICaTOR

The 3D glasses use one lithium-polymer battery inside the right temple.
Battery provides almost 50 hours (active mode) of battery life. The battery
can easily be recharged by charging system. If the glasses are in low battery,
the LED blinks 27 times quickly and turns off automatically. While the glasses
are in charge, LED turns on. When charging is completed, the LED turns off.
Tel: (949) 255-9500 www.BenQ.us
• 3D Glasses (1) • USB Charging Cable (1) • Pouch (1)
• Cleaning Wipe (1) • User Manual (1)
