NEC VT80 Service Manual Supplement

LCD Projector

SERVICE MANUAL SUPPLEMENT
Better Service
Optical alignment jig (optical axis alignment/polarizer alignment)
Better Reputation
Better Profit
NEC DISPLAY SOLUTIONS, LTD.
MODEL VT60 Series
VT70 Series
VT80 Series
VT90 Series
NP3150 Series
NP3250 Series
VT700 Series
VT770 Series
NP905 Series
SAFETY CAUTION:
Before servicing this chassis, it is important that the service
technician read and follow the "Safety Precautions" and
"Product Safety Notice" in this Service Manual.
WARNING:
SHOCK HAZARD - Use an isolation transformer when servicing.
NP600 Series
NP610 Series
NP-M350X Series
NP-M420X Series
NP-M350XS Series
NP-P420X Series
