Lexicon MPX R1 - UPGRADE Update Instructions page 4

Replace Cover
Reposition the bottom plate and replace the six screws. Be
careful not to overtighten the screws.
Replace Front Panel Overlay
1. Remove the old panel overlay by pulling from any
corner.
2. Make sure that the MPX R1 surface is clean.
3. Peel the adhesive backing off of the new overlay and
align the overlay with the MPX R1 using the buttons as
guides.
4. Press the overlay into place and rub the surface to
secure the adhesive bond and to remove any bubbles.
3 Oak Park
Bedford MA 01730-1441
Tel: 781-280-0300
Fax: 781-280-0490
Customer Service Fax: 781-280-0499/e-mail: csupport@lexicon.com
Lexicon Part No. 070-12865
