WAREMA 4MPF AP Installation Instructions

Omnexo Switch actuator
4MPF AP
Installation instructions
General information
Fig. 1 Omnexo Switch actuator 4MPF AP
The Omnexo Switch actuator 4MPF AP is a device for
actuating loads and sun shading drives via four floating
switching outputs.
It is operated via the Omnexo control system. The switch
actuator is supplied with 230 V AC. The power supply
of either 230 V AC or 24 V DC is provided on separate
terminal sets.
The functionality of the Omnexo Switch actuator 4MPF AP
can be parameterised. The control behaviour can be
adjusted to the different requirements of the various
products.
Intended use
The Omnexo Switch actuator 4MPF AP is an electronic
device for controlling sun shading systems or lighting
equipment. The approval of the manufacturer must be
obtained for any use of the device other than its intended
purpose specified in these instructions.
Safety instructions
W ARNING
The electrical installation (assembly)/
dismantling must be performed by a
certified electrician in accordance with
VDE 0100 and/or with the standards
and legal requirements pertaining to
the respective country. The electrician
must observe the installation notes and
instructions included with the electrical
devices supplied.
warema_2066189_alhb_en_v0•2023-12-01
W ARNING
If hazard-free operation cannot be
assumed, the device must not be started
or must be deactivated. This assumption is
justified if:
 the housing or the connecting lines show signs of
damage,
 the device is no longer working.
W ARNING
It is important to comply with the following
points in the interest of personal safety.
Children must not play with the operating elements
of the control unit or the remote control. Store remote
controls out of reach of children.
Make sure that no persons or objects are in the path of
the driven parts (internal and external venetian blinds,
etc.).
Disconnect the device from the operating voltage
if cleaning or other maintenance work must be
performed!
C AUTION
When using window drives, the installer
of the system must ensure that the
safety regulations and precautions
of DIN EN 60335-2-103 "Particular
requirements for drives for gates, doors and
windows" as well as ASR 1.6 "Windows, roof
lights, transparent walls" are observed.
W ARNING
The switch actuators may only be used
to actuate such window drives where the
movement of the window cannot cause any
injuries.
Function of the switch actuator
You will find a detailed description of the functions for the
Omnexo Switch actuators in the Omnexo software. The app
is available to download at www.warema.de/omnexo.
We reserve the right to make technical modifications
Valid from
1 December 2023
Keep for future use.
1
