- Page 1 KS-7410/7412 Fanless Touch Terminal User Manual Package Contents 10” KS-7410 or 12” KS-7412 fanless touch terminal (x 1) Power adapter (x 1) Power cord (x 1) KS-7410/7412 Ver. C0...
- Page 2 SOME IMPORTANT NOTES FCC NOTES This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 3: Battery Warning
ATTENTION Le cordon d'alimentation doit être connecté à une prise de courant avec mise à la terre. BATTERY WARNING Risk of explosion if battery is replaced by an incorrect type. Dispose of expended battery in accordance with local disposal regulations. AVERTISSEMENT DE BATTERIE Risque d'explosion si la batterie est remplacée par un type incorrect. - Page 4 Views of KS-7410 Front View 3-Track Magnetic LED Indicator Stripe Reader 10” P-CAP Touch Panel Base Stand Rear View Display Mounting Holes Cable Cover Cable Exit Left-side View Power Button...
- Page 5 Views of KS-7412 Front View 12” Resistive Touch Panel 12” P-CAP Touch Panel Indicator Indicator Base Stand Rear View Display Mounting Holes Cable Cover Cable Exit Left-side View Power Button...
- Page 6 View of I/O Interface of KS-7410 COM Port (DB9) LAN Port DC-In Power Jack VGA Port Line Out Jack USB 2.0 Ports CR Port COM Ports (RJ50) View of I/O Interface of KS-7412 LAN Port Line Out Jack DC-In Power Jack COM Port (DB9) USB 2.0 Ports...
- Page 7 Connecting VGA and USB Cables The base stand of KS-7410/7412 features its own cable management to help you well organize the cords. The following will provide some useful cable- routing instructions for you to connect VGA and USB cables to KS-7410/7412.
-
Page 8: Status Led Indicator
KS-7410 KS-7412 Powering ON/OFF KS-7410/7412 Power ON KS-7410/7412 Press down the power button to power on the POS. Power OFF KS-7410/7412 In most cases, press the power button of the POS to power the system off. -
Page 9: Power Led
Solid blue System ON Installing an Operating System You are highly advised not to install an operating system on KS-7410/7412 without professional instructions. Not only might the careless handling during installation cause irreversible damage to your machine, but also the improper installation likely leads to system malfunction or failure. - Page 10 KS-7410 KS-7412 1 port, proprietary port connector inside service window Parallel Port (Optional) PS/2 Port Pin header inside service window (Optional) Standard USB Port USB 2.0 x 6 LAN Port 10 / 100 / 1000 Mb x 1 VGA Port...
