- Page 1 1. Product Name Spotlight and Colour Wheel 2. Product Code 20549 3. Colour Black 4. Brief Description Ceiling mounted spotlight with multi‐coloured wheel. 5. Contents Spotlight Colour Wheel Lamp ...
- Page 2 6. Snoezelen® Stimulations • Sight 7. Best Use For maximum effect, use in a darkened room in conjunction with the Revolving Mirror Ball. Ceiling‐mount or use the Wall Bracket. 8. Compatible ROMPA® Products 20547 ‐ 20cm Mirror Ball 20546 ‐ 30cm Mirror Ball 18524 ‐ Motor 1 RPM 18525 ‐ Motor 1/2 RPM 20548 ‐ Replacement Lamp for Spotlight 9. Starting Up • Unscrew the nut and the first tooth ring from the fixing axle of the colour wheel motor. • Remove the protective film of the colour wheel. • Slip the colour wheel onto the spindle motor. • Pass the tooth ring first and then the nut onto the spindle (the rod protruding from ...
- Page 3 11. Safety • For indoor use in dry environments only. • Only connect to an earthed mains outlet of 230Vac/50Hz. • Installation should be carried out by a competent adult. Seek professional advice from a suitably qualified person if in doubt. • We recommend the use of a safety chain or safety mechanism – in the highly unlikely event of the spotlight falling, this would stop the spotlight falling. A solid chain, ...
- Page 4 12. Technical Specification Power: 230Vac, 50Hz Power consumption: 30W Weight: approximately 2kg Size: 15 x 12 x 11.5cm RoHS: RoHS compliant Fuse: 3Amp BS1362 fuse in plug (BSI approved) Cable: 90cm long Lamp: Par 36 6Volt 30Watt Halogen Motor: 6V AC, 50Hz, 2.5 RPM Colour wheel: red, green, yellow, blue. Diameter: 22cm This ...
- Page 5 13. Installation To mount the Colour Wheel Unscrew the nut and the first tooth ring from the fixing axle of the colour wheel motor. Remove the protective film off the colour wheel. ...
- Page 6 Slip the colour wheel onto the spindle motor. Pass the tooth ring first and then the nut onto the spindle (the rod protruding from circular motor). Fasten the nut without damaging the colour wheel. ...
- Page 7 Fix the colour wheel with the motor to the pin spot and tighten the screw. Fix the spotlight to the wall or ceiling using the bracket attached to the spotlight. There is a hole in the bracket to facilitate this. The hole in the bracket is 10mm diameter. Make sure the surface you attach the spotlight can support its weight (approx. 2kg). The motor should be at the bottom. Use an appropriate safety chain or safety mechanism just in case the spotlight should drop. This chain or mechanism must be capable of holding at least 10 times the weight of the fixture. Use only safety ropes with screw‐on carabines. To adjust the angle of the spotlight: release the two knobs (one at each side of the bracket) and turn the bracket. Remember to tighten the screws afterwards! Plug in. ...
- Page 8 14. Care and Maintenance Unplug before any maintenance and allow to cool thoroughly before handling. To change the bulb (20548): Unplug and allow to cool. Remove the fixing ring by pressing it together. ...
-
Page 9: 15. Troubleshooting
Remove the old lamp from the pinspot and loosen the wires. 4. Loosen the screws on the new lamp with an appropriate screwdriver. 5. Connect the wires with the lamp using an appropriate screwdriver. 6. Replace with a new bulb of the same specification: 6V 30W Par 36 lamp (20548). 7. Tighten the screws. 8. Insert the lamp in the housing. 9. Fix the lamp in place with the fixing ring. To clean the lens: Wipe using a slightly damp cloth and dry carefully. 15. Troubleshooting • Check the Spotlight is plugged in. Further copies of these instructions can be downloaded at www.rompa.com We hope you find our instructions invaluable. If you have any suggestions for improving them further your comments will be greatly received – please contact us at producthelp@rompa.com SPOTLIGHT AND COLOUR WHEEL, February 2013 Copyright ROMPA®Ltd...
