  • Page 1 Use and Maintenance Next Plus 15 Spareparts: p. 0800 144 277 varaosat@hako.fi...
  • Page 2 IPX3 MADE IN ITALY Scrubber Dryer Mod: ................Art.: ............... Year: ..... GVW ... kg s/n: ......
  • Page 3 Produttore Caratteristiche elettriche N° Matricola Manufacturer Electrical characteristics Serial N° Producteur Caractéristiques électriques N° Matricule Hersteller Elektrische Eigenschaften Serien-Nr. Fabricante Características eléctricas N° Matrícola Produtor Características elétricas Número de série Producent Elektrische eigenschappen Serienummer Výrobce Elektrické údaje Výrobní č. Изготовитель Электрические...
  • Page 5 Dear Customer, Thank you for choosing one of our cleaning products. The floor scrubber dryer that you have purchased has been designed to satisfy the user in terms of ease of use and reliability over time. We are aware that in order for a good product to stay that way, over time, it requires continuous updates aimed at meeting the expectations of those who use it on a daily basis.
  • Page 6 INDEX INDEX ............................2 TECHNICAL DATA ........................3 1.1 - INTRODUCTION ....................... 4 2.1 - GETTING TO KNOW THE MACHINE (Fig. A) ..............4 3.1 - UNPACKING ........................4 3.1.a - Preliminary operations (Fig. B) ................... 4 3.1.b - Positioning of the handle (Fig. B) ................5 3.1.c - Unloading the machine from the wooden pallet (Fig.

  • Page 7: Technical Data

    TECHNICAL DATA NEXT PLUS 15 PLUS Driving type Walk behind Features Operation power (24V Lithium battery) 547 Wh Supply power 24V dc Installed power 470 W Running time 2 h (547 Wh) Washing track width 385 mm Suction width 477 mm...
  • Page 8 NEXT PLUS 15 PLUS Weight Empty weight 45,4 kg Weight with power supply / battery 48,6 kg Gross vehicle weight (GVW) 65,6 kg 1.1 - INTRODUCTION (18) Squeegee bumper. (19) Detergent solution valve. (19a) Open valve. NOTE: (19b) Closed valve.

  • Page 9: Assembly Components

    WARNING: 3.1.b - Positioning of the handle Use only brushes provided by the (Fig. B) manufacturer according to the model - Unlock the driving handle (1) by pulling of the machine. one of the levers (5) and lift it positioning it Using other types of brushes may at the desired angle.
  • Page 10 5.1 - CHARGING THE 4.1.c - Battery connection (for BATTERY (Fig. F) Lithium version) NOTE: DANGER: The machine is delivered with the battery Charge the batteries in well-ventilat- already installed, connected and with a per- ed areas which comply with stand- centage charge for initial use.

  • Page 11: Machine Controls

    - To turn off the machine, press for 3 sec- NOTE: onds the button (23) When the battery charger is connected to the electrical mains, all machine functions are NOTE: automatically disabled. The machine switches off automatically after - On the display (22 Fig. A), while the bat- 5 minutes of inactivity, press the button (23) tery is charging, the battery icon appears again to restart it.
  • Page 12 Battery (BC version only) NOTE: Indicates the battery charge status: Switching from silent operation to power off 100% (flashing “ ” icon on display), the vacuum system runs for 5 seconds before stopping. - The operation of the suction system is enabled by the levers (4) pressed.

  • Page 13: Machine Handling

    Brush release DANGER: It flashing shown on the display after press- If the detergent comes in contact with the eyes and/or skin or if swallowed, ing for 2 seconds the button (24) refer to the use and safety informa- tion booklet provided by the manu- 8.1 - MACHINE HANDLING facturer of the detergent.
  • Page 14 - If necessary, adjust the amount of delivery Drying only cycle: of the cleaning solution using the button - Repeatedly press the button (25) (25) deactivate the cleaning solution delivery - (Only for BC version) Check the state of system (“ ”...

  • Page 15: Maintenance And Cleaning

    12.1 - MAINTENANCE AND If you plan not to use the machine for more CLEANING than 15 days, you should carry out the follow- ing operations: - Close the detergent solution tap (19b). WARNING: - Disconnect the battery connector (67 Fig. For information and warnings related to maintenance and cleaning opera- tions please follow what is indicated...

  • Page 16: Operations To Perform Weekly

    12.3 - OPERATIONS TO 12.2.b - Cleaning the recovery water PERFORM WEEKLY tank (Fig. H-I) 12.3.a - Cleaning the solution filter WARNING: (Fig. G) At the end of the washing operations, - Close the detergent solution tap (19b). it is compulsory to clean the recov- - Unscrew the transparent cover (58) of the ery water tank to prevent deposits or filter and remove the filter (59).
  • Page 17 12.4.c - Squeegee incidence set up - With the machine turned on and the pres- (Fig. K) ence of the “ ” icon on the display (22), press the levers (4) to start brush rotation - Lower the wiper assembly (15 Fig A) us- until you hear the “CLICK”...

  • Page 18: Parameter Setting

    - Untighten the two lug nuts (69) and the - Press the button (23) to confirm and go positive and negative battery terminals, to the next digit, to finally confirm the and disconnect the (70) and (71) power password and have access to the param- cables.

  • Page 19: Fuse Check/Replacement

    14.1 - FUSE CHECK/ Display setting - Contrast: REPLACEMENT Display tune: NOTE: All machine electrical circuits are protected by auto-resettable electronic devices. The min:0 max:10 safety fuse and relay activates only in case of Display tune Contrasto display serious damage. It is recommended to have the fuses re- - Choose the type of contrast of the display placed by qualified personnel only.
  • Page 20 15.1 - ALARMS DURING THE FUNCTIONING When a machine malfunction takes place, the display (22 Fig A) indicates the type of alarm according to the list shown below. Consult the list and put in place the solution recommended to restore the correct functioning of the machine.

  • Page 21: Troubleshooting

    16.1 - TROUBLESHOOTING PROBLEM CAUSE SOLUTION The machine does not start Low battery (for BC version Check that the battery is only). charged. when pressing the but- ton. See paragraph “Alarms dur- The machine does not work Alarm condition of the elec- ing functioning”.

  • Page 22: Demolition Of The Machine

    PROBLEM CAUSE SOLUTION No cleaning solution comes Empty tank. Fill the tank. out. Closed tap valve. Open the tap valve. Filter clogged. Clean the filter. Pump solenoid valve not Replace the solenoid valve functioning. pump. (*) Defective water pump. Replace the water pump. (*) Faulty electronic board.

  • Page 23: Wiring Diagram

    18.1 - WIRING DIAGRAM Colour codes: Key: Power supply (E) Black Battery (BC) Blue Battery charger (BC) Brown Electronic functions card Green Display Grey Control panel Orange Brush fuse (3A) Pink Water pump fuse (10A) Vacuum fuse (10A) Violet Battery fuse (40A) White Functions card fuse (10A) Yellow...
