VEVOR HV-4-KP Manual

VEVOR HV-4-KP Manual

Rotary table
Hide thumbs

Advertisement

Quick Links

Download this manual
Technical Support and E- Warranty Certificate
www. vevor. com/ support
ROTARY TABLE
MODEL:
HV-4-KP, HV-4-4, HV-4-4R,
HV-6-4, HV-6-4B ,HV-8-4, HV-8-3
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and does not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HV-4-KP and is the answer not in the manual?

Questions and answers

Related Manuals for VEVOR HV-4-KP

Summary of Contents for VEVOR HV-4-KP

  • Page 1 Technical Support and E- Warranty Certificate www. vevor. com/ support ROTARY TABLE MODEL: HV-4-KP, HV-4-4, HV-4-4R, HV-6-4, HV-6-4B ,HV-8-4, HV-8-3 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an...

  • Page 3: Rotary Table

    This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
  • Page 4 Warning-To reduce the risk of injury, user must read instructions manual carefully. PRECISION ROTARY TABLES Two types of Rotary tables are summarized here collectively. The mechanisms common to these tables are shown on some pages of their description. HORIZONTAL/VERTICAL PRECISION ROTARY TABLE This rotary table is designed to...
  • Page 5 SPECIFICATIONS: Unit: mm/inches 4.72” 120mm - 3 -...
  • Page 6 Model HV-3" HV-4" HV-5" F76.2 F110 F127 1.Adjusting Mesh of Worm Gear: Loosen the metal clamp handle and turn the switch metal clockwise until it touches the stopper.The worm gear has now been disengaged.Turn it counterclockwise until it touches the stopper, the worm and gear wheel will engage.Tighten the metal clamp handle after engagement.An additional adjustment can be obtained by removing the screw ④and steel ball and turning the inner screw...
  • Page 7 HORIZONTAL AND VERTICAL TYPE ROTARY TABLE - 5 -...
  • Page 8 Operating Instruction and Function of Each Unit 1.The worm gear ratio is 1:90. one tum of the handle moves the table by 4° Micro-collar is graduated in steps of 1 min. Vernier scale makes settings down to 10 seconds possible. (20 seconds for (HV6) 2.Dividing of 2 to 100 can be carried out quickly and accurately by attaching a Dividing Mechanism.

  • Page 9: Optional Accessories

    OPTIONAL ACCESSORIES DIVIDING PLATES RT with Dividing Plate SPECIFICATIONS FOR DIVIDING PLATES Unit:mm/inches Major dimension of DM Weight Outer Inner Grove width MODEL Dividing Plate set Applicable table diameter of kg/Ib diameter of in handle screw spring clip plate sector am MINI (HV3HV4/HV5) PCD.(32/ 1.26)F...
  • Page 10 In case of An Optional DM Device Attached Indexing of 2 to 100 can be made accurately and quickly. Equation of Indexing Since the worm ratio is 1:90,when the handle is made to rotate a 360°revolution,the table therefore will rotate a 1/90 revolution.The relationships between handle revolution 'N' and individual number 'T' to be sought are shown in the following equation: Remarks:The index table on Page 6 is made on the basis of this equation.
  • Page 11 Operations of Crank Handle and Sector In case of the Example' Division into 29 Equal Parts' aforesaid,it is natural that indexing operation should proceed with the intervals of nine holes after setting the index plate (B plate)on which a row of 87 holes are provided.But in this method,the operator has to count nine holes' intervals one by one.
  • Page 12 Index Table(For worm ratio 1:90) DP-1 For HV6/MINI(HV3/HV4/HV5) - 10 -...
  • Page 13 DP-2 For HV8,HV10,HV12,HV14,HV16 - 11 -...
  • Page 14 Description of in the index table. This table is the one being calculated for the index plate with hole numbers shown below. Description of codes used in the index table T: Desired individual number N: Number of revolutions of the index plate :Option A: Using A plate B: Using B plate...

  • Page 15: Parts List

    PARTS LIST Model HV-4-KP 1. Main body * 1 2. Handle * 2 3. Chuck wrench * 1 4. Reverse jaws * 1 set (3pcs) 5. M10 * 40 T-bolt * 2 6. M10 nut * 2 7. Instructions * 1 Model HV-4-4 1.
  • Page 16 Model HV-4-4R 1. Main body * 1 2. Handle * 2 3. M6 * 55 bolt * 2 4. M6 nut * 2 5. φ 6 flat gasket * 2 6. Positioning block * 2 7. Pressing plate * 2 8.
  • Page 17 Model：HV-6-4 1. Main body * 1 2. Rocker handle * 1 3. M8 * 70 hex socket handle screw * 1 4. M5 * 10 hex socket screw * 4 5. Positioning block * 4 6. M12 * 40 T-bolt * 2, 7.
  • Page 18 Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 E-CrossStu GmbH Mainzer Landstr.69, 60329 Frankfurt am Main. YH CONSULTING LIMITED.
  • Page 20 Technical Support and E- Warranty Certificate www. vevor. com/ support...

This manual is also suitable for:

Hv-4-4Hv-4-4rHv-6-4Hv-6-4bHv-8-4Hv-8-3
