tekmarNet
®
2 Thermostat 527
1.
Location
Exterior
Wall
3.
Install Mounting Base
Adaptor
Plate 007
Thermostat
Base
5.
Switch Settings
Switch Position Action
SETBACK Allow thermostat to respond to
ON
1
available schedule. Requires Timer 033.
OFF
OFF No setback schedule response.
SCENE Allow thermostat to respond to
ON
scenes. Requires User Switch 479.
2
OFF
OFF No scene response.
LOCK Locked to 'User' access level. Set
ON
to Lock when installation completed.
3
UNLOCK Unlock to access all settings.
OFF
Set to Unlock during installation.
ON
Not used
4
OFF
Not used
Quick Setup Guide
Interior
Wall
5 feet
1.5 m
Thermostat
Base
OR
Switch
Box
2.
Remove Mounting Base
4.
Wiring
Wall
tN2 Manager, Module
or Wiring Center
6.
Close Thermostat
pivot
tab
1 of 2
Zoning
Replaces: 08/10
tNt 527
One Stage Heat
ON
For instructions see brochure
Use at least 65°C conductors
1 2 3 4
tN2
tN2
1
2
1
2
Switch
Setting
Location
tN2 tN2
© 2011
Q 527
12/11
3
4
Q 527 - 12/11
Advertisement
Related Manuals for Tekmar tNt 527
Summary of Contents for Tekmar tNt 527
- Page 1 Location Remove Mounting Base Interior Wall 5 feet 1.5 m Exterior Wall Wiring Install Mounting Base tNt 527 One Stage Heat Adaptor Plate 007 Thermostat Base Thermostat Base For instructions see brochure Use at least 65°C conductors 1 2 3 4...
- Page 2 ® controls or download the brochure from www.tekmarcontrols.com tekmar Control Systems Ltd., Canada, tekmar Control Systems, Inc., U.S.A. Head Offi ce: 5100 Silver Star Road, Vernon, B.C. Canada V1B 3K4, 250-545-7749, Fax. 250-545-0650 Web Site: www.tekmarcontrols.com Product design, software and literature are Copyright © 2011 by: All specifications are subject to change without notice.
