- Page 1 Installation manual PV Solar MODULE Please read this manual carefully before operating your set and retain it for future reference. N-TYPE MODELS LGXXXN1C(W)-E6 LGXXXN1K-E6 LGXXXN1T-E6 www.lg-solar.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY ..............03 BEFORE & AFTER INSTALLATION ......05 Before Installation ................05 After Installation ...................05 ELECTRICAL INSTALLATION .......06 Danger ....................06 Electrical Connections .................06 Diodes ....................06 Series Connection ................06 Parallel Connection ................07 General Wiring..................07 Earth Grounding ..................07 MECHANICAL INSTALLATION ......08 Module Mounting .................08 Site Consideration ................08 Mounting Methods ................08... -
Page 3: Safety
SAFETY The instructions related to safety and use indicated No electrical parts like cables are in the this installation manual are intended for the located after installation between prevention of unexpected danger, damage, or failure. laminate and mounting structure. DANGER WARNING CAUTION Non-compliance with the instructions may cause product... - Page 4 Do not touch the glass surface or Module frame of the solar module after Module Installing structure installation of the module. It may Installing structure (Stralght type) (bent type) result in injury or death. Heavy objects must be kept off of the solar module.
-
Page 5: Before & After Installation
BEFORE & AFTER INSTALLATION Before Installation • Be careful not to damage the cable when using a tool Please carefully read this manual before installation. such as a knife to remove the cable tie that fixes the • Solar module installation and maintenance must be junction box cable. -
Page 6: Electrical Installation
ELECTRICAL INSTALLATION Danger Diodes • Avoid all electrical hazards when installing, wiring, • All LG modules are equipped with factory installed operating and maintaining all panels. bypass diodes. The factory-installed diodes provide proper circuit protection for the module from • Do not connect panels that have different electrical unexpected shadows. -
Page 7: Parallel Connection
(Maintenance is especially important in areas with high levels of salt in the atmosphere, such as coastal • LG Electronics recommends that all wiring be double areas and the surrounding seas.) insulated with a minimum rating of 90°C (194°F). -
Page 8: Mechanical Installation
Shadow Module Mounting • LGE solar module should be installed in a proper site • The LG Electronics’ (LGE) Limited Warranty for solar that there is no shadowing affected by building, chimney, tree, and neighboring module, etc. modules is contingent upon modules being mounted in accordance with the requirements described in this section. - Page 9 Nut. • The solar module may be mounted by using the Module frame following methods: (*Torque:8~12N∙m) • LG modules (Fire performance : Type 1 or 2) shall be Spring washer Flat washer with CSA/UL61730. • It is recommended to check with local authorities...
-
Page 10: Disclaimer Of Liability / Disposal
Disclaimer of Liability • By beginning to installation process, the installer has to read and completely understand this Installation Manual. • If installer had any questions regarding this installation manual, the installer would have contacted LG with any questions or concerns. -
Page 11: Product Specifications
PRODUCT SPECIFICATIONS N-TYPE Rated electrical characteristic except power rating within -0/+3 percent are within 5 percent of measured. Values at Standard Test Condition(STC) : Irradiance 1000W/m , Cell temp. 25℃, 1.5AM Electrical Properties Mechanical Properties Max. Max. Max. Pmax Pmax Module Pmax Power... - Page 12 PRODUCT SPECIFICATIONS Electrical Properties(NMOT*) LGXXXN1C(W)-E6 Model Maximum Power (Pmax) MPP Voltage (Vmpp) 31.4 31.8 32.1 32.4 32.7 33.0 33.4 33.6 MPP Current (Impp) 8.53 8.56 8.60 8.62 8.65 8.69 8.72 8.75 Open Circuit Voltage (Voc) 37.4 37.8 38.1 38.5 38.8 39.2 39.5 39.9...
-
Page 13: Dimensions Of Modules
Dimensions of Modules Unit: mm / in. LGXXXN1C(W)-E6 / LGXXXN1K-E6 / LGXXXN1T-E6 60Cell Module Note) Cable length with connector (MC4, 05-8, PV-CO02) Frame Cross section Long Frame Short Frame... -
Page 14: Appendix
Position Load (mm) Front/Rear(Pa) (mm) Front/Rear(Pa) 0~300 2400/2400 0 ~ 300 5400/2400 800~900 5400/4000 Note) All mechanical installation methods and bolting method in this appendix were not tested by CSA or 3rd party. It is evaluated by LG internal test. - Page 15 Position Load Position Load (mm) Front/Rear(Pa) (mm) Front/Rear(Pa) 0~334 240~440 2400/2155 2155/2155 240~440 0~334 Note) All mechanical installation methods and bolting method in this appendix were not tested by CSA or 3rd party. It is evaluated by LG internal test.
-
Page 16: Bolting & Clamp Information
• Follow the clamp manufacturer’s recommended applied torque to fasten the clamps. • Depth <Edge Clamp> Note) All mechanical installation methods and bolting method in this appendix were not tested by CSA or 3rd party. It is evaluated by LG internal test. -
Page 17: Alternate Equipment Grounding Devices
LG Module Install manual and listed manufacture’s installation guide. These alternative grounding devices indicated on this page have been evaluated and approved by LG, not by CSA or 3rd Party. Please review the racking system or grounding device listing for compatibility and ratings. -
Page 18: Unloading Flow Guide
Unloading Flow Guide If you are unloading using heavy equipment such as a crane, please follow the procedure below. [ Step 1 ] [ Step 2 ] [ Step 3 ] [ Step 4 ] Step 1. Place the packaging on a flat surface. Step 2. - Page 19 2000 Millbrook Dr., Lincolnshire, IL 60069 Contact : lg.solar@lge.com http://www.lgsolarusa.com This document is subject to change without notice. LG, LG logo and Life's Good are trademarks of LG Electronics, Inc. worldwide. Trademarks and intellectual properties of LG Electronics, Inc. are protected by international copyright laws.
