Display Tablet

DB-15 Diagnostic Connector
(To connect to vehicle's DLC (Data
Link Connector) via diagnostic cable.)
Charging Port
(To connect to external DC
power for charging the tool.)
Charging LED
(Red: Charging.
Green: Fully
charged.)
OK Button
1
Charging & Turning On
There are two charging methods available:
Via Charging Cable: Plug one end of the included charging cable
into the charging port of the tool, and the other end to an external
charger or an AC outlet with USB ports.
Via Diagnostic Cable: Insert one end of the diagnostic cable into
the DB-15 connector of the tool, and the other end to the vehicle's
DLC.
Once the charging LED illuminates solid green, it indicates that the
battery is fully charged.
Press the [Power] button to power it on.
5" Touch Screen
Selection Buttons
Power/Screen
Lock Button
HOME Button
Return Button
2

Getting Started

If it is the first time you have used this tool, you need to make some
system settings and keep the diagnostic software synchronized with
the latest version.
Follow the steps below to proceed.
Tap "Start" on Welcome screen
Select system language
Select time zone
WLAN setup
Configure email address
Sign user agreement
Job Menu appears
Tap "Update"
*Note: After you configured it, the
system will automatically send the
diagnostic report to your email
box every time a complete Auto-
Detect process is successfully
finished.
*Note: To enjoy more capabilities
and better service, you are
strongly recommended to update
it on regular basis.
