With the proper installation and maintenance it will provide many years of service. Please Note: To achieve maximum performance and insure long life from your Munters product it is essential that it be installed and maintained properly. Please read all instructions carefully before beginning installation. Warranty: For Warranty claims information see the “Warranty Claims and Return Policy”...
Any shipping damage is the customer’s responsibility and should be reported immediately to your freight carrier. Each Munters Drive G2 FM3465 Kit Includes: 1 – Munters Drive G2 Motor 1 – Hardware Package As Follows: HP2603 –...
Page 6
Installation Instructions Step 3 Loosen the (4) captured screws in the Munters Drive Box cover to access the drive wiring. Disconnect 3 wires on the right side of the drive from the terminals “U/T1, V/T2, W/T3”. Then replace the cover.
Page 9
Chapter 2 Installation Instructions Step 6 Remove the (4) bolts holding the Heat Sink with Control Box to the back of the Munters Drive Motor and carefully set the Heat Sink with Control Box in fan. See Figure 6. Discard the (4) bolts removed.
Page 10
Motor. See Figure 7. If you were instructed by Munters office to send the old Motor back to the office, repack it in the box that the new Motor came in to send back. Motor...
Page 12
Align the Wiring Entrance and (4) mounting holes in the Heat Sink with the Wiring Entrance and (4) mounting holes in the back of the Munters Drive Motor and secure in place with (4) Bolts [C]. Tighten Bolts to 60 in-lbs.
Page 15
Installation Instructions Step 12 Loosen the (4) captured screws in the Munters Drive Box cover to access the drive terminals. Reconnect the 3 wires on the right side of the drive from the terminals “U/T1, V/T2, W/T3”. Then replace the cover.
Page 18
Installation Instructions Step 16 Loosen the (4) captured screws in the Munters Drive Box cover to access the drive wiring. Disconnect 3 wires on the right side of the drive from the terminals “U/T1, V/T2, W/T3”. Then replace the cover.
Page 21
Chapter 2 Installation Instructions Step 19 Remove the (4) bolts holding the Heat Sink with Control Box to the back of the Munters Drive Motor and carefully set the Heat Sink with Control Box in fan. See Figure 19. Discard the (4) bolts removed.
Page 22
Motor. See Figure 20. you were instructed by Munters office to send the old Motor back to the office, repack it in the box that the new Motor came in to send back.
Page 24
Align the Wiring Entrance and (4) mounting holes in the Heat Sink with the Wiring Entrance and (4) mounting holes in the back of the Munters Drive Motor and secure in place with (4) Bolts [C]. Tighten Bolts to 60 in-lbs.
Page 27
Installation Instructions Step 25 Loosen the (4) captured screws in the Munters Drive Box cover to access the drive terminals. Reconnect the 3 wires on the right side of the drive from the terminals “U/T1, V/T2, W/T3”. Then replace the cover.
Page 28
Munters Drive replacement kit is developed and produced by Munters Corporation, Lansing, Michigan U.S.A. 1-800-227-2376 Munters Europe AB, Isafjordsgatan 1, P.O. Box 1150, SE-164 26 Kista, Sweden. Phone +46 08 626 63 00, Fax +46 8 754 56 66. Munters Corporation 2691 Ena Drive Lansing, MI 48917 U.S.A. Phone +1 800-227-2376, Fax +1 517-676-7078 www.munters.us...
