- Page 1 Scan me on your phone camera to watch our assembly video. USER MANUAL WC02010001 PRODUCT CODE:...
- Page 2 Aluminium Traveller Wheelchair is the ideal companion designed to provide you with maximum comfort whilst increasing independence in your daily life. Due to CareCo’s commitment to continuous product improvement, product information and designs are subject to change without notice. No claims can be made based on the data or illustrations in this user manual.
-
Page 3: Before Use
We recommend that you keep this user manual in a safe place for future reference. If you have any questions about product use, maintenance, or safety, please contact CareCo. KEY DEFINITIONS... -
Page 4: Table Of Contents
WC02010001 PRODUCT CODE CONTENTS GETTING STARTED CARTON CONTENTS PRODUCT COMPONENTS SETTING UP YOUR ALUMINIUM TRAVELLER WHEELCHAIR HOW TO USE YOUR WHEELCHAIR TRANSFERING TO & FROM GRADIENTS THRESHOLDS & FIXED OBSTACLES APPLYNG THE BRAKES ATTENDANT BRAKE LEGREST FOOTPLATES ADDITIONAL STORAGE SPACE FOLDING, TRANSPORTING &... - Page 5 LOOKING AFTER YOUR WHEELCHAIR CLEANING MAINTENANCE MAINTENANCE SCHEDULE REPAIRS OTHER ADJUSTMENTS BRAKE ADJUSTMENT ATTACHING A SEAT BELT WARNINGS & TECHNICAL INFORMATION SPECIFICATIONS PRODUCT REISSUING RECYCLING & DISPOSAL INTENDED USE INTENDED USER PRODUCT IDENTIFICATION GENERAL WARNINGS EXPECTED LIFETIME WARRANTY NOTES...
-
Page 6: Getting Started
WC02010001 PRODUCT CODE GETTING STARTED CARTON CONTENTS Contact CareCo immediately if ITEM NUMBER DESCRIPTION QUANTITY any of the listed contents are Aluminium Traveller Wheelchair missing. Calf Rest Strap We strongly recommend that Footrest Set you keep the box and internal... -
Page 7: Setting Up Your Aluminium Traveller Wheelchair
SETTING UP YOUR ALUMINIUM TRAVELLER WHEELCHAIR 1. Remove all wheelchair components from 2. Pull the armrests away from each other to the outer packaging and place them onto open the wheelchair. a level surface. 3. Lift the backrest upwards. 4. Place the legrest(s) onto the frame at a 90-degree angle, then rotate inwards. - Page 8 WC02010001 PRODUCT CODE 5. Loop the heel strap velcro over the legrest and secure.
-
Page 9: How To Use Your Wheelchair
HOW TO USE YOUR WHEELCHAIR USER INSTRUCTIONS TRANSFERING TO & FROM Always ensure the brakes are applied before getting in/out of the wheelchair. TRANSFER TO Position your body as close to the wheelchair as possible. Support your body using the armrests, before lowering into the seat. TRANSFER FROM Support your body using the armrests and place your feet on the ground. -
Page 10: Thresholds & Fixed Obstacles
WC02010001 PRODUCT CODE THRESHOLDS & FIXED OBSTACLES Approach thresholds vertically to avoid wheelchair misbalance. SUGGESTION Use caution when operating the wheelchair near kerbs, ledges, and doorway thresholds. DOORS & GATES Determine whether the door/gate opens towards or away from the user. Reach for the handle and carefully move forwards or backwards depending on the door/gate orientation. -
Page 11: Applyng The Brakes
APPLYING THE BRAKES ATTENDANT BRAKE STOPPING Gradually squeeze both brake levers to stop the wheelchair. Release the brake levers to start moving again. TURNING Squeeze the left and right brake levers individually to rotate the wheelchair. Release the brake lever to stop rotating. LOCKING Locate the locking lever in the handle catch to lock the attendant brake. - Page 12 WC02010001 PRODUCT CODE LEGRESTS ATTACHING REMOVING Place the legrest(s) onto the frame at a Lift the legrest lever(s) to release the leg 90-degree angle, then rotate inwards. rest(s) from the frame, then rotate outwards. An audible “click” will confirm the legrest(s) Lift the legrest(s) away from the frame.
-
Page 13: Additional Storage Space
ADDITIONAL STORAGE SPACE CARECO WHEELCHAIR BAG POPEM PANNIER BAG Attach additional storage space to the back Attach additional storage space to the side of your wheelchair by looping the bag straps of your wheelchair by looping the bag straps over the wheelchair’s push handles. -
Page 14: Folding, Transporting & Storing Your Wheelchair
WC02010001 PRODUCT CODE FOLDING, TRANSPORTING & STORING YOUR WHEELCHAIR FOLDING INSTRUCTIONS 1. Apply the locking brakes. 2. Lift the legrest levers to release the leg rests from the frame, then rotate outwards. Repeat on the other side. 3. Lift the seat canvas handles upwards to 4. -
Page 15: Transportation
TRANSPORTATION STOWING THE WHEELCHAIR Ensure the brakes have been applied and any accessories have been secured before transporting. Fold the wheelchair, then lift it into the desired vehicle. Position the wheelchair appropriately within the vehicle to prevent excess movement during transit. -
Page 16: Comfort Adjustments
WC02010001 PRODUCT CODE COMFORT ADJUSTMENTS FOOTPLATE HEIGHT ADJUSTMENT Difficulty Level Moderate High 1. Using a spanner, loosen the hex head at the base of the footrest. 2. Lift or lower the footplate until it is at the desired height. 3. Tighten the hex head to secure the position. -
Page 17: Maintenance Schedule
REPAIRS Certain wheelchair components can be repaired by the user with guidance provided by CareCo. Other components can only be repaired/replaced by a service technician. If for any reason the wheelchair requires repair due to a defect, contact CareCo immediately. -
Page 18: Other Adjustments
WC02010001 PRODUCT CODE OTHER ADJUSTMENTS BRAKE CABLE ADJUSTMENT Difficulty Level Moderate High Tools Required 8MM Spanner x1 10MM Spanner x1 1. Loosen the lock nut (B) by rotating it anticlockwise. 2. Adjust the brake cable tension by rotating the brake adjuster (A). 3. -
Page 19: Specifications
WARNINGS & TECHNICAL INFORMATION SPECIFICATIONS OVERALL LENGTH WITH FOOTREST ATTACHED (MM) OVERALL LENGTH (MM) OVERALL WIDTH (MM) OVERALL HEIGHT (MM) FOLDED LENGTH (MM) FOLDED WIDTH (MM) FOLDED HEIGHT (MM) FRONT WHEEL DIAMETER (IN) REAR WHEEL DIAMETER (IN) CARRY WEIGHT (KG) WEIGHT CAPACITY (KG) SEAT WIDTH (MM) SEAT DEPTH (MM) -
Page 20: Material Information
Ensure the product is safe and functions as intended before re-issuing. RECYCLING & DISPOSAL Recycling or disposal of the wheelchair should be completed through an approved distributor or disposal facility. (Local disposal & recycling regulations may apply) Alternatively, contact CareCo for advice on disposal. MATERIAL INFORMATION UPHOLSTERY ALUMINIUM... -
Page 21: Product Identification
PRODUCT IDENTIFICATION The product identification label is located on the cross frame. 974231 100683 DEFINITIONS Model number Refer to instruction manual Batch code Caution Date of manufacturer Indicates electrical / electronic equipment must be disposed of in accordance with the WEEE regulation. Manufacturer’s address Keep away from rain Product expiry date... -
Page 22: General Warnings
WC02010001 PRODUCT CODE GENERAL WARNINGS Read the following carefully to avoid damage and/or injury caused by improper operation. • Do not exceed the maximum user weight indicated on the frame label. • Do not stand on the product or the footrests at any time. •... -
Page 23: Expected Lifetime
EXPECTED LIFETIME The Expected Lifetime is the estimated period of time for which the rollator is expected to function according to its intended use. Various items such as weight capacity, user behaviour, external conditions and intensity of use can affect the expected lifetime. WEIGHT CAPACITY: USER BEHAVIOUR: If the user exceeds the weight limit specified,... -
Page 24: Warranty
Parts that have been purchased by the end user after the original warranty period has expired have a warranty period of 12 months. CareCo is not responsible if the wheelchair requires repair or replacement as a direct result of: •... - Page 25 NOTES...
- Page 26 2406-01...
