Keep handles dry, clean and free from oil and grease.
9
Remove adjusting keys and wrenches: Form the habit of checking to see that keys and adjusting wrenches are removed from the
9
tool before turning it on.
Avoid unintentional starting: Ensure switch is in off position when plugging in.
9
Stay alert: Watch what you are doing, use common sense and do not operate the tool when you are tired.
9
Check damaged parts: Before further use of tool, it should be carefully checked to determine that it will operate properly and perform
9
its intended function.
Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting and any other conditions that may affect its
9
operation.
A guard or other part that is damaged should be properly repaired or replaced by an authorized service centre unless otherwise
9
indicated in this instruction manual.
Have defective switches replaced by an authorised service centre. DO NOT use the tool if the switch does not turn it on and off.
9
WARNING! The use of any accessory or attachment other than one recommended in this instruction manual may present a risk of
‰
personal injury.
Have your tool repaired by a qualified person: This electric tool complies with the relevant safety rules. Repairs should only be carried
9
out by qualified persons using original spare parts, otherwise this may result in considerable danger to the user.
2. INTRODUCTION
tr
Steel chassis with locking blade wheel covers. Smooth operation by bearing-mounted blade wheels and belt drive induction motors. Micro
switches prevent operation when either blade wheel cover is open. 2-Speed operation enables bandsaw to cut multiple types of materials.
Fitted with tilting tables for cutting compound mitres. Fully adjustable blade tracking and tensioning for precise cutting action. Features
quick adjusting rip fence, mitre gauge, dust extraction port, blade wheel brushes and push sticks. Supplied with metal stand.
3.

SPECIFICATION

MODEL NO:
Blade Length
Cutting Speed
Dust Extraction Diameter
Fuse Rating
Maximum Cutting Height
Motor Power
Nett Weight
Noise/ Sound pressure
Plug Type
Power Supply Cable Length
Supply
Table Size
Table Tilt
Throat Depth
The declared noise emission value(s) have been measured in accordance with a
standard test method and may be used for comparing one tool to another.
The declared noise emission value(s) may be used in a preliminary assessment of exposure.The noise emissions during actual use
of the power tool can differ from the declared values depending on ways in which the tool is used especially what kind of workpiece is
processed. A warning of the need to identify safety measures to protect the operator, that are based on an estimation of exposure in the
actual conditions of use.
4. FEATURES
A Blade tension adjustment knob
B Blade cover screw
C Blade guard height adjuster
D Blade guard
E Fence
F No Volt On/Off switch
G Fence lock handle
© Jack Sealey Limited
SM1304.V3
1712mm
400/730m/min
Ø60mm
5A
1000mm
370W
32kg
LpA: 88.4 dB(A) /
LwA: 101.4 dB(A)
3-Pin
2m
230V 50Hz
340 x 335mm
0-45°
245mm
MAIN FEATURES (fig.1 / fig.2)
H Table side guide
I Mitre guide
J Band saw blade
K Extraction outlet
L Tracking adjustment knob
M Worktable
Original Language Version
fig.2
fig.1
SM1304.V3 Issue:1 08/11/24
fig.2a
