Jumper FV-98 Instruction Manual

FV-98
BT 3-mode screen display mechanical keyboard
Lighting use:///////////////////////////////////////////////////////////////////
FN+W：LX98-BT1
FN+E： LX98-BT2
FN+R： LX98-BT3
FN+Q,W,E short press to enter the corresponding hook-back state. The blue light of the
corresponding key blinks slowly, and the connection is up or over When the blue goes out.
Press and hold for more than 3s to enter the corresponding pairing state, and the red light
flashes accordingly.Connected or timed out, red off. (Bluetooth indicator light on prompt mode)
Press FN+T to enter the corresponding 2.4G hookback state. The blue light of the corresponding
key blinks slowly to indicate that the connection is up or over When the blue goes out. Press and
hold for more than 3s to enter the corresponding pairing state, and the red light flashes accordingly.
Connected or timed out, red off. (2.4G indicator steady on prompt mode)
Light mode/Light effect/Backlight brightness/Volume/System toggle switches within the screen
FN+ direction to switch the screen page left/right, press FN+ENTER on the mode page to enter
the mode adjustment, then Use FN+ direction to adjust the desired function left/right, and then
press FN+ENTER to return to the screen page.
All modes are switched according to the display
+ +
BT
Product specifications: //////////////////////////////////////////////////////////////
Key function description://///////////////////////////////////////////////////////
FN + F1= Music
FN + F2= Sound -
FN + F3= Sound +
FN + F4= Silent
FN + F5= Stop
FN + F6= Last song
FN + F7= Play/pause
FN + F8= Next song
FN + F9= Mail
FN + F10= Home page
FN + F11= My computer
FN+F12= Calculator
FN+ESC Hold down 3s to restore the factory light effect
Flip the switch to switch BT/Wired /2.4G
Sleep function://////////////////////////////////////
After the wireless keyboard is connected to the device, it goes into hibernation without
operation for 1 minute. Click any key to wake up the original state.
Specification item 3-mode screen display mechanical keyboard
Product number: FV-98
Keyboard interface: TYPE-C
Connection method: Wired+2.4G+BT
Luminous Type: RGB Backlight
Product type: Mechanical shaft
Number of keys: 98 KEY
Button life: 20 million times or more
Operating Voltage:
3.7V DC
Battery capacity: 2000mAh
Product Size: 390* 150*50mm (± 2mm)
No impact button: Support full key conflict free,
Keycap material: ABS
Product line length: 1500mm±30mm
Multimedia: Support FN+12 key combinations
System compatibility: Mac OS X10, 12, iOS10 or later
