RTKA489EPRDK0010BU

140W USB Type-C Battery System Reference Design for 2 to 7S Li-Ion

Description

The RTKA489EPRDK0010BU (RTK-G015-EPRSinkCharger (140W)) is a Universal Serial Bus Power Delivery

(USB PD) evaluation board that supports 2 to 7 battery cells in series configuration. The

RTK-G015-EPRSinkCharger is designed with 48V USB-C Port Controller (SPR/EPR TCPC) RAA489400, USB-C

Port Manager (TCPM) R9A02G0151, and On-Board Charger RAA489118. There are two types of RTK-G015-

EPRSinkCharger-140W supports 28V/140W USB Type-C

for the RTK-G015-EPRSinkCharger.

The RTK-G015-EPRSinkCharger supports USB PD 2.0, USB PD 3.1, and USB Type-C Specification. The

RTK-G015-EPRSinkCharger works as a USB Type-C EPR power sink charger or an EPR power bank. The

RTK-G015-EPRSinkCharger does not have a battery protection circuit on the board, so, Renesas strongly

recommends using a battery module with Renesas' Battery Management System to avoid over-discharging under

the power bank mode. The RTK-G015-EPRSinkCharger may be combined with an Evaluation Module of the

Battery Fuel Gauging IC (FGIC) RAJ2400100 with Filefish to realize a complete Battery Management System

(BMS).

The configuration switches enable the selection of the number of battery cells, the maximum charge current and

the operating mode.

VIDWriter 1.2.1.0 applies to the RTK-G015-EPRSinkCharger.

Target Devices

▪ 140W USB Type-C Charger or MAX 140W Power Bank: RTK-G015-EPRSinkCharger-140W

• 48V USB-C Port Controller (SPR/EPR TCPC): RAA489400

• USB-C Port Manager (TCPM): R9A02G0151

• On-Board Charger: RAA489118

▪ Evaluation Module of Battery Fuel Gauging IC (FGIC) with Filefish: RAJ240100 Filefish EVM

• Battery Fuel Gauging IC: RAJ240100

Target VIDWriter: VIDWriter 1.2.1.0 (Version 1.2.1.0)

Need help?

Do you have a question about the RTKA489EPRDK0010BU and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas RTKA489EPRDK0010BU

Page 1 RTK-G015-EPRSinkCharger works as a USB Type-C EPR power sink charger or an EPR power bank. The RTK-G015-EPRSinkCharger does not have a battery protection circuit on the board, so, Renesas strongly recommends using a battery module with Renesas’ Battery Management System to avoid over-discharging under the power bank mode.
Page 2: Table Of Contents
Renesas BMS Interface ........... 16 3.2.3 Charging Battery Module with Renesas BMS Interface ......16 3.2.4 Power Bank Mode Setting .
Page 3: Features
◦ Charging Current limits control for R9A02G0151 • On-chip debugging emulator interface ◦ Renesas on-chip debugging emulator interface to write and debug firmware for R9A02G0151 • Battery Management System interface ◦ Renesas BMS evaluation board interface to communicate with Battery module including FGIC •...
Page 4: Block Diagram
RTKA489EPRDK0010BU Manual Block Diagram Figure 1. RTK-G015-EPRSinkCharger-140W Block Diagram (RTKA489EPRDK0010BU: 28V EPR Mode) R16UZ0115EU0101 Rev.1.01 Page 4 Feb 12, 2025...
Page 5: Component
RTKA489EPRDK0010BU Manual Component 1.2.1 Component Layout TP81 TP90 SW1B JP16 JP15 Top Side Bottom Side Figure 2. Highlighted Main Parts on the RTK-G015-EPRSinkCharger-140W Board R16UZ0115EU0101 Rev.1.01 Page 5 Feb 12, 2025...
Page 6: Component Information
U9A1 ISL80101 (3.3V output LDO) Table 2. Connectors Description Remark USB Type-C receptacle Renesas on-chip debugging emulator interface USB2.0 Data interface TB1/J17 Connector for Battery Management System SMBus Controller 2 SCL, SDA on R9A02G0151 P70, P71 SMBus Controller 1 SCL, SDA alert on R9A02G0151...
Page 7: Function Assignment For Raa489400 On Rtk-G015-Eprsinkcharger
RTKA489EPRDK0010BU Manual Function assignment for RAA489400 on RTK-G015-EPRSinkCharger Table 6 shows the functions assigned to RAA489400 on RTK-G015-EPRSinkCharger. Table 6. Functions Assigned to RAA489400 Pins on RTK-G015-EPRSinkCharger Pin name Function Descriptions NC_1 Open Configuration Channel 1, Analog pin from CC-PHY Rd resistor 1, Analog pin from CC-PHY.
Page 8: Function Assignment For R9A02G0151 On Rtk-G015-Eprsinkcharger
RTKA489EPRDK0010BU Manual Function assignment for R9A02G0151 on RTK-G015-EPRSinkCharger Table 7 shows the functions assigned to R9A02G0151 on RTK-G015-EPRSinkCharger. Table 7. Functions Assigned to R9A02G0151 Pins on RTK-G015-EPRSinkCharger Pin name Function Descriptions TOOL0 Connected to on-chip debugging emulator interface for flash programming.
Page 9: Function Assignment For Raa489118 On Rtk-G015-Eprsinkcharger
RTKA489EPRDK0010BU Manual Function assignment for RAA489118 on RTK-G015-EPRSinkCharger Table 8 shows the functions assigned to RAA489118 on RTK-G015-EPRSinkCharger. Table 8. Functions Assigned to RAA489118 Pins on RTK-G015-EPRSinkCharger Pin name Function Descriptions CSON CSON Battery current sense negative input CSOP CSOP...
Page 10: Function
RTKA489EPRDK0010BU Manual Function Battery Configuration Battery Configuration is set by SW1B. Table 9. Rotary switch setting value for Battery Configuration SW Position RTK-G015-EPRSinkCharger 2 Cells in series 3 Cells in series 4 Cells in series 5 Cells in series 6 Cells in series 7 Cells in series The standard charger parameters in firmware (FW) define MaxSysVol/cell as 4.048V and MinSysVol/cell as...
Page 11: Charging Current Limits
RTKA489EPRDK0010BU Manual MaxSysVol represents the maximum battery charging voltage. It is defined as Full in this document. If VBAT reaches the Full value, the charger operates in Constant Voltage mode. MinSysVol represents the minimum allowed voltage during discharging mode. It is defined as Empty in this document. In charging mode, when VBAT is less than the Empty value, the Charger trickle charges the battery at a low current level.
Page 12: Operating Mode Selection
RTKA489EPRDK0010BU Manual that the battery module has. Therefore, the SW1B setting is ignored at this case. FW is generated by VIDWriter 1.2.1.0 (see Firmware Writing to the R9A02G0151 on RTK-G015-EPRSinkCharger). If SW1 does not have a suitable charging current value and/or user does not want to set MaxSysVol and MinSysVol as standard values, user needs to set SW1 to SW position 0 and set the expected charging current value, MaxSysVol and MinSysVol.
Page 13: Sinking Mode
Note: The RTK-G015-EPRSinkCharger does not have a battery protection circuit on the board, therefore, Renesas strongly recommends using a battery module with Renesas’ Battery Management System to avoid over-discharging under the power bank mode. RTK-G015-EPRSinkCharger can support power bank mode as R16UZ0115EU0101 Rev.1.01...
Page 14 RTKA489EPRDK0010BU Manual long as the battery module uses protection circuit to avoid over-discharge or over-temperature. However, this should be done at user’s own risk. Under sourcing mode for Power Bank operating, RTK-G015-EPRSinkCharger supports the standard maximum sourcing PD Power as shown in...
Page 15: Board Setup And Usage
28V, EPR cable is required.) Note: This board does not require an external power supply except for the batteries. IMPORTANT: USE THIS BOARD WHEN YOU UNDERSTAND AND AGREE THAT RENESAS DOES NOT HAVE ANY RESPONSIBILITY, INDEMNIFICATION, OR LIABILITY FOR USE OF THIS BOARD.
Page 16: Charging Battery Module With The Custom Charger Parameters (Manual Mode) Without Renesas Bms Interface
5. FW of RTK-G015-EPRSinkCharger retrieves the maximum charging voltage and current limits using the Renesas BMS interface and sets the appropriate battery charger value on RTK-G015-EPRSinkCharger. 6. Connect a USB Type-C sourcing device to the USB Type-C receptacle (CN1) using a USB Type-C Cable and supply power to the battery module.
Page 17: Power Bank Mode Setting
Figure 7. Power Indicator for Source Mode Battery Module with Renesas BMS Interface Battery module with Renesas BMS interface is described in this section. Renesas release Filefish that is a fixed firmware solution for Renesas Battery Fuel Gauging IC (FGIC), which requires no additional firmware development.
Page 18: Raj240100 Filefish Evm
Refer to RAJ240100 Filefish User’s Manual R01AN6763EJ for more details. Figure 9. RAJ240100 Filefish EVM Note: Minimum number of cells for Filefish (RAJ240100) is 3 cells in series. For more information about Filefish, contact your Renesas representative. R16UZ0115EU0101 Rev.1.01 Page 18...
Page 19: Firmware Writing To The R9A02G0151 On Rtk-G015-Eprsinkcharger
RTKA489EPRDK0010BU Manual Firmware Writing to the R9A02G0151 on RTK-G015-EPRSinkCharger This section describes how to generate and write the firmware (such as Intel HEX file) to the R9A02G0151 in an appropriate method. 3.4.1 FW Generation 3.4.1.1 Operating Environment ▪ Host PC •...
Page 20 Figure 11. Main Window for VIDWriter 1.2.1.0 after Product Configuration 5. Field E configures the turnkey solution recommended by Renesas. ‒ Field E is used to set the Full, Empty, Max Charging Current, and Max sourcing PDP (DRP mode). There are three operating modes: Board, BMS, and Manual.
Page 21 RTKA489EPRDK0010BU Manual Figure 12. Field E and the EVB Setting versus Board Configuration Full indicates the maximum battery charging voltage. Empty indicates the voltage the charger trickle charges the battery at a low current level if VBAT is below that value.
Page 22 RTKA489EPRDK0010BU Manual Figure 14. Field E and the EVB Setting versus Manual Configuration If there is no suitable charging current value on SW1 and/or if setting Full and Empty as standard values is not required, set SW1 to SW position 0 and set the expected charging current value, Full and Empty. Full indicates the maximum battery charging voltage.
Page 23: Outline Of Flash Memory Writing
7. Finally, when you press the Create FW Data button, a file save dialog is displayed. The default storage location is the My Documents folder. The save location and file name of the ROM image can be changed if required. If rewriting this ROM image to R9A02G0151 on the evaluation board, use the Renesas Flash Programmer V3 programming software.
Page 24: Fw Writing With Renesas On-Chip Debugging Emulator
3.4.3 FW Writing with Renesas On-Chip Debugging Emulator Writing (load) firmware by Renesas on-chip debugging emulator is available. Since RTK-G015-EPRSinkCharger does not have full 14-pin connector for the emulator, connecting using a converter is required The converter is made with the bundled cable when using Renesas on-chip debugging emulator.
Page 25 RTKA489EPRDK0010BU Manual 6. Select the RL78 in the Microcontroller drop-down list, input an arbitrary name in the Project Name field. 7. Select your on-chip debugging emulator product in the Tool drop-down list. 8. Click the Tool detail and select the 3.3V in the Power Supply area, then click Connect.
Page 26 RTKA489EPRDK0010BU Manual 10. Select the Erase, Program, and Verify in the Operation Settings tab. Figure 20. Operation Settings Tab 11. Click Start to start programming the flash memory data Figure 21. Operation Tab - Start Programming R16UZ0115EU0101 Rev.1.01 Page 26...
Page 27: Optional Features
RTKA489EPRDK0010BU Manual 12. OK is indicated if the program is completed successfully. Figure 22. Successful Program Indicator Optional Features Supports USB Peripheral Function RTK-G015-EPRSinkCharger is designed for Sink only (SNK) Charger / Power Bank turnkey solution. There is no USB data communication feature on this board. It has an interface to expand the test/debug of USB2.0-based peripheral function with system.
Page 28: Supports Smbus Target Interface
Figure 24. Connector for SMBus Target Interface To control the RTK-G015-EPRSinkCharger board using an external controller through the SMBus Target Interface, connect the SMBus Controller signaling of the system J1. When the system wants to control RTK-G015-EPRSinkCharger, contact Renesas for support. Ordering Information Part Number...
Page 29 Renesas' products are provided only subject to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
