- Page 1 HT32F67233 Starter Kit User Guide Revision: V1.00 Date: April 02, 2024...
-
Page 2: Table Of Contents
HT32F67233 Starter Kit User Guide Table of Contents 1. Introduction ....................... 3 Features ............................3 2. Hardware Layout ....................4 3. Connection between the e-Link32 Lite and the Target Board ....10 4. Schematics ...................... 11 Rev. 1.00 April 02, 2024... -
Page 3: Introduction
-M0+ high performance ® ® microcontroller and is designed to assist users to get up and running with the Holtek 32-bit device range as quickly as possible. Standard C language programs can be developed using the integrated development environment from Keil μVision and IAR EWARM. -
Page 4: Hardware Layout
Lite SWD-10P translation CMSIS-DAP UART Jumper switch Target Board SWD-10P RF option 5V-to-3.3V Jumper Regulator reset 8 MHz Power LED2 LED1 HT32 MCU ARM Cortex- Power Jumper Microcontroller Micro HT32F67233 Starter Kit Block Diagram Rev. 1.00 April 02, 2024... - Page 5 HT32F67233 Starter Kit User Guide HT32F67233 Starter Kit Layout Separating the e-Link32 Lite Not Separated (Default) Separated Serial Wire Debug Interface Switch – S1 Description Connect the SWD interface between the e-Link32 Lite and the Target MCU – default setting Disconnect the SWD interface between the e-Link32 Lite and the Target MCU Rev.
- Page 6 HT32F67233 Starter Kit User Guide SWD-10P Connector – CN2, CN6 CN2 is the Serial Wire Debug interface connector on the e-Link32 Lite side, while CN6 is on the Target Board side. SWD-10P Connector • SWD-10P Connector Pin No. Description Pin No.
- Page 7 HT32F67233 Starter Kit User Guide MCU Power Jumper – J1 Description The MCU VDD pin is connected to the 3.3V power – default setting The MCU VDD pin is disconnected from the 3.3V power The jumper is useful when it is required to measure the MCU power consumption.
- Page 8 HT32F67233 Starter Kit User Guide • Extension Connector 1 Pin No. Description Pin No. Description PA4/RS232_RX PA5/RS232_TX PA14 PB14 PA9/Boot pin PB13 PB0EX PB7EX PB7EX PB7EX PB12EX 3.3V 3.3V Extension Connector CN4-2 Extension Connector 2 Rev. 1.00 April 02, 2024...
- Page 9 HT32F67233 Starter Kit User Guide • Extension Connector 2 Pin No. Description Pin No. Description 3.3V 3.3V PA9/Boot pin nRST PA12/SWCLK PA13/SWDIO PB7EX PB0EX PB3/LED1 PA15 PB3/LED1 PB8/LED2 Micro USB Type B Connector – CN5 Micro USB Type B Connector •...
-
Page 10: Connection Between The E-Link32 Lite And The Target Board
HT32F67233 Starter Kit User Guide 3. Connection between the e-Link32 Lite and the Target Board Connection between e-Link32 Lite V2.2 and Target Board The diagrams above are the schematic diagram of the connection between the e-Link32 Lite and the Target Board: •... -
Page 11: Schematics
This section shows the HT32 MCU Starter Kit circuit diagrams: • e-Link32 Lite V2.2 • HT32F67233 Target Board – ESK32-30601 Other Starter Kit target board circuit diagrams can be downloaded on Holtek official website. e – Link32 Lite V2.2 HT32F67233 Target Board – ESK32-30601 Rev. - Page 12 HOLTEK disclaims all liability arising from the information and its application. In addition, HOLTEK does not recommend the use of HOLTEK’s products where there is a risk of personal hazard due to malfunction or other reasons. HOLTEK hereby declares that it does not authorise the use of these products in life-saving, life-sustaining or safety critical components.
