Epson EB-595Wi Quick Start Manual

HOME › PRODUCTS › PROJECTORS › EPSON EB-595WI
Epson EB-595Wi
Overview
The ultra-short-throw EB-595Wi is the world's first 3LCD, touch-enabled interactive projector. Offering 3x Brighter Colours
ensure bright, vivid lessons. With 3300 lumens of colour brightness
learning to new heights. With touch- and pen-based interactivity, the 595Wi makes it easy to draw and collaborate using any wall and familiar, intuitive gestures. Teachers
2
can use the Moderator software to simultaneously share students' work from multiple devices
1
Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15.4; white light output measured
in accordance with ISO 21118.
2
Moderator feature is part of Epson's EasyMP Multi PC Projection software.
3
Check your owner's manual to determine if a wireless LAN module must be purchased separately to enable wireless connection on your Epson projector. Epson projectors can be networked either through the
Ethernet port on the projector (check model specifications for availability) or via a wireless connection. Not all Epson projectors are able to be networked. Availability varies depending on model.
*
Compared to leading 1-chip DLP business and education projectors based on NPD data, July 2011 through June 2012. Colour brightness (colour light output) measured in accordance with IDMS 15.4. Colour
brightness will vary depending on usage conditions.
KEY FEATURES & BENEFITS
Brighter images – Now with up to 3,300 lumens white brightness and colour brightness.
Longer lamp life – Up to 6,000 hours
Higher contrast ratio – Now with 10,000:1 across the entire range.
Digital connectivity – 2x HDMI ports for digital connections. 1 port supports MHL (Mobile High Definition Link) for mirroring connectivity with Android
PC Interactivity – Comes with Epson's latest and enhanced PC interactive software (Easy Interactive Tools version 3.0). With intuitive user interface and enhanced
interactive features.
Wireless projection and interactivity – Projection and interactive function without the wires when used with the optional LAN card (using peer to peer wireless and
Epson's EasyMP Network Projection software version 2.81 or later).
Multi-user Interactivity – With simultaneous dual pen functionality and finger touch interactivity, teacher and students can annotate at the same time using 2 pens and up
to 6 fingers! New smaller pen design now comes with selectable function side button.
Projector control using Multi-PC projection software with Moderator function – Allows up to 50 devices to connect to the projector. Now features a Moderator function for
managing and controlling the images displayed on the screen (up to 4).
New projector control tool bar – Allows user to control the projector (eg switch sources, zoom, volume up/down etc) using the interactive pen.
No driver installation required – Installation has never been easier (driver installation is required for Mac).
Advanced Networking Capability – Enables users to monitor, control and present from a remote location.
Low cost Epson Lamp – Incredibly low price of only $95 RRP inc GST.
16W Built-in Speaker – Built in audio with the power to fill the room.
#
Lamp life for the EB-575W and EB-575Wi is up to 10,000 hours (eco mode) and 5,000 hours (normal); lamp life for the EB-580, EB-585W, EB-585Wi and EB-595Wi is up to 6,000 hours (eco mode) and 4,000
hours (normal). Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp Brightness decreases over time.
Model
Interactivity
White Light Output
Colour Light Output
Display Technology
Native Resolution
Aspect Ratio
Contrast Ratio
Multi-user Interactivity
PC Free Annotation
Network Functionality
Wireless LAN
HDMI Connectivity
Speakers
Integrated Mount Included
Zoom Ratio
Education Model
Low Cost Replacement Lamp
#
Lamp Hours
1
and 3300 lumens of white brightness
#
lamp life in ECO mode.
Interactive Ultra Short Throw Models - Range at the glance
EB-585Wi
Pen only
3,300 lumens
3,300 lumens
3LCD
WXGA
16:10
10,000:1
YES
YES
YES
Optional
x2 (x1 supports MHL)
16W
YES
1.35x (Digital)
-
YES ($129RRP)
4,000 (Normal), 6,000 (ECO)
Ultra Short Throw Projectors
Touch brilliance - the world's first 3LCD, touch-
enabled interactive projector
Printer Friendly Specs
than competitive models, Epson 3LCD projectors
*
1
, the 595Wi delivers truly dynamic images. And, it takes kinesthetic
3
.
EB-595Wi
Finger and Pen Interactive
3,300 lumens
3,300 lumens
3LCD
WXGA
16:10
10,000:1
YES
YES
YES
Optional
x2 (x1 supports MHL)
16W
YES
1.35x (Digital)
-
YES ($129RRP)
4,000 (Normal), 6,000 (ECO)
™
mobile devices.
