  • Page 1 SEN00986-11 BULLDOZER D375A -5E0 50001 SERIAL NUMBERS and up...

  • Page 2: Machine Model

    SEN00988-11 BULLDOZER 1SHOP MANUAL D375A-5E0 Machine model Serial number D375A-5E0 50001 and up 00 Index and foreword Index Composition of shop manual .......................... 2 Table of contents ............................. 4 D375A-5E0...
  • Page 3 SEN00988-11 00 Index and foreword Composition of shop manual The contents of this shop manual are shown together with Form No. in a list. Note 1: Always keep the latest version of this manual in accordance with this list and utilize accordingly. The marks shown to the right of Form No.
  • Page 4 00 Index and foreword SEN00988-11 Troubleshooting by failure code, Part 5 SEN01873-02 Troubleshooting by failure code, Part 6 SEN01874-00 Troubleshooting by failure code, Part 7 SEN01891-00 Troubleshooting of electrical system (E-mode) SEN01875-02 Troubleshooting of hydraulic, mechanical system (H-mode) SEN01876-01 Troubleshooting of engine (S-mode) SEN01877-01 50 Disassembly and assembly SEN01005-02...
  • Page 5 SEN00988-11 00 Index and foreword Table of contents 00 Index and foreword Index SEN00988-11 Composition of shop manual....................... Table of contents ......................... Foreword and general information SEN00989-04 Safety notice..........................How to read the shop manual ..................... Explanation of terms for maintenance standard................Handling of electric equipment and hydraulic component............
  • Page 6 00 Index and foreword SEN00988-11 Recoil spring ..........................Idler ............................. Track roller ..........................Carrier roller ..........................10 Track roller bogie......................... Track shoe........................... 12 Main frame ..........................16 Suspension ..........................18 Hydraulic system, Part 1 SEN00997-01 Work equipment hydraulic piping diagram .................. PPC control piping diagram ......................
  • Page 7 SEN00988-11 00 Index and foreword 30 Testing and adjusting Testing and adjusting, Part 1 SEN01932-02 Tools for testing, adjusting, and troubleshooting ................. Testing engine speed ........................Testing intake air pressure (boost pressure) ................Testing exhaust temperature ....................... 11 Testing exhaust gas color......................13 Adjusting valve clearance......................
  • Page 8 00 Index and foreword SEN00988-11 Using method of KOMTRAX functions of ORBCOMM terminal ..........33 Precautions for replacing VHMS controller ................. 36 Pm Clinic service......................... 42 40 Troubleshooting Failure code table and fuse locations SEN01867-02 Failure codes table ........................Fuse locations ..........................12 General information on troubleshooting SEN01868-02 Points to remember when troubleshooting..................
  • Page 9 SEN00988-11 00 Index and foreword Failure code [2302LH] When left steering brake oil pressure command current is ON,  fill signal is OFF........................46 Failure code [2302NR] Left steering brake thermal load abnormality ......... 48 Failure code [6001ZK] Failure code for design ................48 Failure code [A000NS] Engine overheat ..................
  • Page 10 00 Index and foreword SEN00988-11 Failure code [CA449] Common rail pressure abnormally high pressure 2........75 Failure code [CA451] Common rail pressure sensor abnormally high level ....... 76 Failure code [CA452] Common rail pressure sensor abnormally low level ......... 78 Failure code [CA553] Common rail pressure abnormally high pressure 1........
  • Page 11 SEN00988-11 00 Index and foreword Failure code [DB3SKR] Steering controller S-NET communication error........24 Failure code [DBB0KK] (or VHMS LED display "n901") VHMS supply voltage abnormality..26 Failure code [DBB0KQ] (or VHMS LED display "nF11") VHMS connector connection  abnormality........................... 28 Failure code [DBB3KK] (or VHMS LED display "n905") VHMS controller battery direct ...
  • Page 12 00 Index and foreword SEN00988-11 Failure code [DH22KA] Work equipment pump oil pressure sensor 1 disconnection ....60 Failure code [DH22KB] Work equipment pump oil pressure sensor 1 short circuit..... 62 Failure code [DH23KA] Work equipment pump oil pressure sensor 2 disconnection ....64 Failure code [DH23KB] Work equipment pump oil pressure sensor 2 short circuit.....
  • Page 13 SEN00988-11 00 Index and foreword Failure code [DXH1KA] Lockup solenoid disconnection ............. Failure code [DXH1KB] Lockup solenoid short circuit..............Failure code [DXH1KY] Lockup solenoid hot short ..............Failure code [DXH4KA] 1st clutch ECMV disconnection............. 10 Failure code [DXH4KB] 1st clutch ECMV short circuit ..............12 Failure code [DXH4KY] 1st clutch ECMV hot short..............
  • Page 14 00 Index and foreword SEN00988-11 E-14 The hydraulic oil temperature gauge does not indicate normally ........34 E-15 Indication of the fuel gauge is abnormal................35 E-16 Indications of gear speed and engine speed are abnormal..........36 E-17 Indication of the shift mode service meter is abnormal ............36 E-18 The switch module cannot be operated................
  • Page 15 SEN00988-11 00 Index and foreword S-11 Coolant contains oil (blows back or reduces)..............22 S-12 Oil pressure lamp lights up (drop in oil pressure) ............... 23 S-13 Oil level rises (Water, fuel in oil)..................24 S-14 Coolant temperature rises too high (Overheating).............. 26 S-15 Abnormal noise is made .....................
  • Page 16 00 Index and foreword SEN00988-11 Disassembly and assembly of bogie assembly................32 Removal and installation of 1st bogie assembly ................. 34 Undercarriage and frame, Part 2 SEN02368-01 Expansion and installation of track shoe assembly..............Whole disassembly and assembly of track shoe ................ Dimensions table of fitting jig of link press ..................
  • Page 17 SEN00988-11 00 Index and foreword Electrical circuit diagram (13/13) ....................27 Electrical circuit diagram for inside cab ..................29 Air conditioner unit electrical circuit diagram ................31 Connectors table and arrangement drawing ................33 D375A-5E0...
  • Page 18 00 Index and foreword SEN00988-11 D375A-5E0...
  • Page 19 SEN00988-11 00 Index and foreword D375A-5E0 Bulldozer Form No. SEN00988-11  © 2009 KOMATSU All Rights Reserved Printed in Japan 09-09 D375A-5E0...
  • Page 20 SEN00989-04 BULLDOZER 1SHOP MANUAL D375A-5E0 Machine model Serial number D375A-5E0 50001 and up 00 Index and foreword Foreword and general information Safety notice ..............................2 How to read the shop manual ......................... 7 Explanation of terms for maintenance standard ..................... 9 Handling of electric equipment and hydraulic component ................11 Handling of connectors newly used for engines ...................

  • Page 21: Safety Notice

    Proper service and repair are extremely important for safe machine operation. The service and repair techniques recommended by Komatsu and described in this manual are both effective and safe. Some of these techniques require the use of tools specially designed by Komatsu for the specific purpose.
  • Page 22 00 Index and foreword SEN00989-04 Preparations for work When removing a cover which is under Before adding oil or making any repairs, internal pressure or under pressure from a park the machine on a hard and level spring, always leave 2 bolts in diagonal ground, and apply the parking brake and positions.
  • Page 23 SEN00989-04 00 Index and foreword Precautions for sling work and making signs Only one appointed worker must make signs and co-workers must communicate with each other frequently. The appointed sign maker must make specified signs clearly at a place where he is well seen from the operator's seat and where he can see the working condition easily.
  • Page 24 00 Index and foreword SEN00989-04 If the load is unstable or the wire rope 13) If the hoist stops because of a power fail- or chains are twisted, lower the load ure, turn the power switch OFF. When and lift it up again. turning on a switch which was turned OFF Do not lift up the load slantingly.
  • Page 25 SEN00989-04 00 Index and foreword a Example of O-ring (Fitted to every joint of Precautions for disconnecting and con- necting hoses and tubes in air conditioner hoses and tubes) circuit Disconnection For the environment, the air condi- tioner of this machine uses the refrigerant (air conditioner gas: R134a) which has fewer factors of the depletion of the ozone layer.
  • Page 26 Engine volume This section explains the method of reproducing, repairing, and replacing parts. Revision and distribution Any additions, revisions, or other change of notices will be sent to KOMATSU distributors. Get the most up-to-date information before you start any work. D375A-5E0...
  • Page 27 SEN00989-04 00 Index and foreword Filing method File by the brochures in the correct order of the form number printed in the shop manual composition table. Revised edition mark q q q q When a manual is revised, the ones and tens digits of the form number of each brochure is increased by 1.
  • Page 28 00 Index and foreword SEN00989-04 Explanation of terms for maintenance standard The maintenance standard chapter explains the criteria for replacing or reusing products and parts in the machine maintenance work. The following terms are used to explain the criteria. Standard size and tolerance To be accurate, the finishing size of parts is a little different from one to another.
  • Page 29 SEN00989-04 00 Index and foreword Standard clearance and standard value Clearance limit The clearance made when new parts are Parts can be used until the clearance assembled is called the “standard clear- between them is increased to a certain ance“, which is indicated by the range limit.
  • Page 30 00 Index and foreword SEN00989-04 Handling of electric equipment and hydraulic component To maintain the performance of the machine over a long period, and to prevent failures or other troubles before they occur, correct “operation“, “maintenance and inspection“, “troubleshooting“, and “repairs” must be carried out.
  • Page 31 SEN00989-04 00 Index and foreword Disconnections in wiring If the wiring is held and the connectors are pulled apart, or components are lifted with a crane with the wiring still connected, or a heavy object hits the wiring, the crimping of the connector may separate, or the sol- dering may be damaged, or the wiring may be broken.
  • Page 32 00 Index and foreword SEN00989-04 Removing, installing, and drying connec- tors and wiring harnesses Disconnecting connectors Hold the connectors when discon- necting. When disconnecting the connectors, hold the connectors. For connectors held by a screw, loosen the screw fully, then hold the male and female connectors in each hand and pull apart.
  • Page 33 SEN00989-04 00 Index and foreword Connecting connectors Check the connector visually. Check that there is no oil, dirt, or water stuck to the connector pins (mating portion). Check that there is no deformation, defective contact, corrosion, or dam- age to the connector pins. Check that there is no damage or breakage to the outside of the con- nector.
  • Page 34 00 Index and foreword SEN00989-04 Heavy duty wire connector (DT 8-pole, 12- Disconnection Connection (Example of pole) incomplete setting of (a)) Disconnection (Left of figure) While pressing both sides of locks (a) and (b), pull out female connector (2). Connection (Right of figure) Push in female connector (2) horizon- tally until the lock clicks.
  • Page 35 SEN00989-04 00 Index and foreword Drying wiring harness If there is any oil or dirt on the wiring har- ness, wipe it off with a dry cloth. Avoid washing it in water or using steam. If the connector must be washed in water, do not use high-pressure water or steam directly on the wiring harness.
  • Page 36 00 Index and foreword SEN00989-04 Handling controller The controller contains a microcomputer and electronic control circuits. These con- trol all of the electronic circuits on the machine, so be extremely careful when handling the controller. Do not place objects on top of the control- ler.
  • Page 37 SEN00989-04 00 Index and foreword Points to remember when handling hydraulic equipment With the increase in pressure and precision of hydraulic equipment, the most common cause of failure is dirt (foreign material) in the hydraulic circuit. When adding hydraulic oil, or when disassembling or assembling hydraulic equipment, it is necessary to be particularly careful.
