front runner
Mercedes Sprinter H2 Ladder
LAMS003
READ ME !
Thank you for purchasing a Front Runner Mercedes Sprinter H2 Ladder.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the included components.
Refer to Page 2 for a list of all the components, quantities and tools required.
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
LAMS003_REV_A00
1
© 2023 FRONT RUNNER VEHICLE OUTFITTERS

Advertisement

loading
Need help?

Need help?

Do you have a question about the LAMS003 and is the answer not in the manual?

Questions and answers

Summary of Contents for Front Runner LAMS003

  • Page 1 FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL. NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
  • Page 2 Torx 10 X M6 Nut Cap 10mm 6.5mm 13 X M6 Nyloc Nut M6 x 20 Button Head Bolt Anti- Anti- M6 x 20 x 2 Flat Washer Seize Rust Marker FIGURE 1.1 LAMS003_REV_A00 © 2023 FRONT RUNNER VEHICLE OUTFITTERS...
  • Page 3 Ladder Side (Item 3) using M6 x 16 Button Head Bolts and M6 Nyloc Nuts (Items 2 & 12) as shown. Place M6 Nut Caps (Item 11) over all Nyloc Nuts. 10mm Anti- Seize LAMS003_REV_A00 © 2023 FRONT RUNNER VEHICLE OUTFITTERS...
  • Page 4 Loosely fit the Ladder using the M8 Nyloc Nuts and M8 x 16 Button Head Botls (Item 19) as shown. NOTE: This Ladder can not be mounted behind the sliding side door. Side Profile End Cap LAMS003_REV_A00 © 2023 FRONT RUNNER VEHICLE OUTFITTERS...
  • Page 5 Congratulations! You did it. Take a step back and admire your work! INSTALL OTHER VEHICLE AND RACK ACCESSORIES Now's the time to visit your favorite Front Runner Dealer in person or online. Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam...
