Kilotech KPC 5000-2 Technical Service Bulletin

Technical Service Bulletin :
MODELS : KPC 5000-2/5
ACTION : Calibration Manual
_____________________________________________________________________________________________
1. Keep pressing "MODE" button first, then press "ON/TARE" button to
power on the scale, after self-examine, the scale will display the inner code
"06000" (the inner code should be within 20000), now loose "MODE"
button.
2. Press "ON/TARE" button again, the reading will be 00000, now put the
max. capacity weight of 5kg on the scale, after 3-5 seconds, press
"ON/TARE" button again, the scale will display 20000, then the calibration
has been done.
3. Press "OFF" button to power off the scale.
4. Power on the scale, put the 5kg weight on the scale again and check if the
scale show the correct weight, if yes, the calibration succeed, if not, follow
step 1-3 again.
Aug 18, 1999
Rev 00
K I L O T E C H
Work Instructions WI-4.19-TSB-AD-001
