Asus SAMRT3000 V5 Q670 Manual page 25

RS-485
Pin Signal
1 485-
3 NC
5 GND
7 NC
9 NC
3. LAN (RJ-45) port. This port allows 2.5 Gigabit connection to a Local Area
Network (LAN) through a network hub.
LAN port LED indications
Activity/Link LED
Status
Off
Green
Green (Blinking)
Green (Blinking
then steady)
2-18
Pin
2
4
6
8
Description
No link
Linked
Data activity
Ready to wake
up from S5
mode
Signal
485+
NC
NC
NC
Speed LED
Status Description
OFF 10Mbps/100Mbps
connection
ORANGE 1Gbps connection
GREEN 2.5Gbps
connection
ACT/LINK
LED
LAN port
SAMRT3000 V5 Q670
SPEED
LED
