Forney 250 MP PRO WELDER Quick Start Manual

ITEM# 415
MIG QUICK START GUIDE
250 MP PRO WELDER
1.
Read user
manual.
2.
Set correct polarity.
Solid wire
For solid
wire place
polarity
jumper in
the POS (+)
dinse
3.
Load the wire into the machine using the appropriate despooler size. Guide the wire through the drive
system, ensuring the drive roll matches the wire's diameter.
4.
Connect the MIG
gun to the unit.
8.
Adjust secondary parameters.
Turn the SECONDARY
PARAMETER KNOB to scroll
through and highlight the
secondary parameters in grey.
Flux-core
For flux-core
place
polarity
jumper in the
NEG (-)
dinse
5.
Connect the gas input
if necessary.
Expert-Tech
™
SET for 3 seconds to set highlighted
secondary parameter to Forney's Expert Set
value.
Press the SECONDARY
PARAMETER KNOB to select the
highlighted secondary parameter.
The highlight will change to green.
6.
Connect to
input power.
• Generator OK with continuous output >
4,000W (120V) or 10,500W (240V).
• Extension Cord: Use #12 AWG or larger.
Extension cords should be 25' (8m) or
shorter are recommended.
Tip: At any time; HOLD EXPERT
Turn the SECONDARY
PARAMETER KNOB to adjust the
green highlighted secondary
parameters.
MIG Gun
Ground
Clamp
7.
Select Manual MIG process.
For TruSet™ MIG jump to step 10
Press the SECONDARY
PARAMETER KNOB to save the
selected secondary parameters.
The highlight will turn grey.
