IDTECK STAR FINGER 007 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ID TECK
STAR FINGER007
ACCESS CONTROLLER
USER΄S MANUAL
STAR FINGER007
Access Controller
ID-TECK CO., LTD.
FINGER007-20011128
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAR FINGER 007 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IDTECK STAR FINGER 007

Summary of Contents for IDTECK STAR FINGER 007

  • Page 1 ID TECK STAR FINGER007 ACCESS CONTROLLER USER΄S MANUAL STAR FINGER007 Access Controller ID-TECK CO., LTD. FINGER007-20011128...

  • Page 2: Table Of Contents

    ID TECK STAR FINGER007 ACCESS CONTROLLER Table of Contents 1. Important Safety Instructions 2. General 3. Features 4. Specification 5. Front Panel Description 6. Identifying Supplied Parts 7. Installation of the Product 8. Color Coded & Wiring Table 9. System Wiring for Typical Application 10.

  • Page 3: Important Safety Instructions

    ID TECK STAR FINGER007 ACCESS CONTROLLER 1. Important Safety Instructions When using your STAR FINGER007 Single door controller, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons. In addition, the following safety guides should also be followed: 1.

  • Page 4: Features

    ID TECK STAR FINGER007 ACCESS CONTROLLER 3. Features • Single door controller for access control and time & attendance, network capable, up to 32 units in a string • Built-in Proximity Reader with up to 4" of read range with IDC 170 Card •...

  • Page 5: Front Panel Description

    ID TECK STAR FINGER007 ACCESS CONTROLLER 5. Front Panel Description 3LEDS (showing Fingerprint input system status) window Function Key 16 Numeric Keypad 6. Identifying Supplied Parts Please unpack and check the contents of the box. Main Unit Wall Mount O-Ring Manual ( 1 ) ( 1 )

  • Page 6: Installation Of The Product

    ID TECK STAR FINGER007 ACCESS CONTROLLER 7. Installation of the Product 7-1. Tear off last page and use the provided template to drill two 6-32 holes and one 1/2" hole on the proper location of the wall to mount the Wall Mount bracket as shown below. (If the gang box is already installed on the wall then skip this step.) 7-2.

  • Page 7: Color Coded & Wiring Table

    ID TECK STAR FINGER007 ACCESS CONTROLLER 8. Color Coded & Wiring Table I/O PORT NAME SIGNAL NAME COLOR CODED POWER Main Power (+12V) +12V Red wire Power Ground Black wire OUTPUT Door RELAY(COM) COM(1) Gray wire with Red stripe Door RELAY(NC) NC(1) Blue wire with White stripe Door RELAY(NO)

  • Page 8: System Wiring For Typical Application

    ID TECK STAR FINGER007 ACCESS CONTROLLER 9. System Wiring for Typical Application 9-1. Power Connection - Connect (+) wire of DC 12V power to Red wire - Connect Power GND (-) wire of DC 12V to Black wire 9-2. Door Lock Connection 9-2-1 Connection of POWER FAIL SAFE : Door Lock - Connect Door RELAY(COM), Grey/Red stripe wire to DC +12V (be sure that the existing power supply has enough capacity to support this accessory or upgrade to a sufficient one.)
  • Page 9 ID TECK STAR FINGER007 ACCESS CONTROLLER 9-3. Alarm Device Connection - Connect Alarm RELAY(COM), White wire to DC +12V (be sure that the existing power supply has enough capacity to support this accessory or upgrade to a sufficient one.) - Connect (+) wire of Alarm Device to Alarm RELAY(NO), Purple wire of main unit. - Connect (-) wire of Alarm Device to Power GND(-) wire of main unit.

  • Page 10: Wiring For Network

    ID TECK STAR FINGER007 ACCESS CONTROLLER 10. Wiring for Network 11. Functions 11-1. Standalone Operation. The STAR FINGER007 is capable of having two readers(entry and exit). The unit receives card data signals from the RF readers and determines whether or not to unlock the door. When an input signal is sent, for example from and activated sensor or if the exit button pressed, the controller generates and logs an appropriate response.

  • Page 11: Anti-Pass-Back

    ID TECK STAR FINGER007 ACCESS CONTROLLER 11-5. Anti-Pass-Back Using an additional RF reader for exiting, the Anti-Pass-Back mode can be utilized. Anti-Pass-Back prevents a registered user from exiting if the user did not properly register when entering. Likewise if the user has exited without verification by the unit, the user will not be allowed entry on their next attempt.

  • Page 12: Operation

    ID TECK STAR FINGER007 ACCESS CONTROLLER 12. Operation 12-1. Normal Operation Mode (Safe Mode) When the Main Unit operates in standby mode(waiting for ID), the red LED is lit. 12-2. Open the Door When a registered card(or PIN) and Fingerprint(using fingerprint) are read, the Door will open for 3 seconds. Registered Card (or PIN) 12-3.

  • Page 13: Basic Setting

    ID TECK STAR FINGER007 ACCESS CONTROLLER 13. BASIC SETTING 13-1. Basic operation If you turn on the system power after POWER ON connected 3 wires (pink, cyan and black(GND)), you can enter system initialize mode. GENERAL BOOT H/W RESET MODE INITIAL BEEP( - - - -) INITIALIZE BEEP( - - -) In the system ready, LCD...

  • Page 14: System Initialize

    ID TECK STAR FINGER007 ACCESS CONTROLLER 13-2. H/W reset You can H/W initialize using extra reader port. First, turn off the system power and connect 3 wires (pink, cyan and black(GND)), and turn on the system power. Then you can hear “Initialize beep(• ••)” and display ○ 1 picture. And then, Please execute “System Initialize”...
  • Page 15 ID TECK STAR FINGER007 ACCESS CONTROLLER 13-3. Enter into setup menu INITIAL DISPLAY (MODEL NAME, CURRENT TIME) ID INPUT ? MASTER ID ? OPERATE GENERAL DISPLAY ERROR STATUS WAITING MASTER P/W MODE RIGHT ? THE INITIAL MASTER ID IS "0000000" AND P/W IS "3141"...

  • Page 16: Time Setting

    ID TECK STAR FINGER007 ACCESS CONTROLLER 13-4. Setting the date and time (See 14.1.2) Select ‘Time setting’ in “Setup menu1” and enter the data of year /month /date /hour /minute /second /day (15digit) as the illustration below shows. You will see the adjusted time on the LCD when finished. Master card(PIN)/ Password/Fingerprint Select ‘Time Setting’...
  • Page 17 ID TECK STAR FINGER007 ACCESS CONTROLLER 13-5. Registering Cards(IDs) You can register Cards(or PIN) to the system. (See, 14.3.1) Select ‘ID REGISTRATION’ in Setup menu F3, follow through illustration below shows. 1) Flowchart ID REGISTRATION 'ENT' REGISTRATION SELECT (setup mode F3) FINGER007 (FINGER007) CARD or KEY ?
  • Page 18 ID TECK STAR FINGER007 ACCESS CONTROLLER 2) ID Registration Master Card(PIN)/ Password/Fingerprint FINGER_007 [F1] Select ID Registration MM/DD hh:mm:ss menu (Setup menu F3) Initial Master pin(<00000000>)/ Initial password(<3141>) Initial display ID REGISTRATION ID REGISTRATION 1 - Card, 2 - Key 1.
  • Page 19 ID TECK STAR FINGER007 ACCESS CONTROLLER 2. Registration by Keypad (Finger007 & Finger007P) Key InPut ID 00000100 Input Registration <2>key Card ID : PW1234 TS00 RD3 FPX key (4digit) Input PW/TS/RD/FP Not using fingerprint(FP:0) Using fingerprint To Register FP Lift and Put FP Success Success Completionㅜ...

  • Page 20: Setting Changes

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14. Setting Changes 1. Enter into setup menu INITIAL DISPLAY (MODEL NAME, CURRENT TIME) To set or to change the Finger007 access controller's ID INPUT ? operation, enter the eight-digit Master number or CARD. (cf.

  • Page 21: Setup Menu F1

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1 Setup Menu F1 SETUP F1 MENU MODE SELECTION RF Only (ID Only) SEARCHING KEY RF+FINGER(P/W) (ID+FINGER(P/W)) TIME SETTING RF+P/W+FINGER (ID+P/W+FINGER) SEARCHING KEY TYPE SELECTION STAND ALONE SEARCHING KEY FINGER_007P APB SETUP NOT USE SEARCHING KEY ALL CLEAR COMM ID SETTING...

  • Page 22: Mode Selection

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.1 Changing Operating Mode MODE SELECTION RF Only (ID Only) SELECT KEY RF+FINGER(P/W) (ID+FINGER(P/W)) 'ENT' SELECT KEY RF+P/W+FINGER (ID+P/W+FINGER) This menu is to select operating mode. You can choose whether to use MODE SELECTION password(or fingerprint) to each access or not.

  • Page 23: Type Selection

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.2 Time Setting TIME SETTING 'ENT' ENTER "YYYYMMDDhhmmssW" The lower line on the LCD indicates present time. To set time, press <ENT> TIME SETTING key. MM/DD hh:mm:ss Enter the correct information of the year, month, date, hour, minute, second, day code in due order, then the setting is finished.
  • Page 24 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.4 Anti-Pass-Back Setup APB SETUP NOT USE SELECT KEY 'ENT' SELECT KEY ALL CLEAR You can select whether the Anti-Pass-Back(APB) is used or not. The lower line APB SETUP on the LCD indicates the current mode. To change mode, press <ENT> key. NOT USE Press <4>...

  • Page 25: Comm Address

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.5 Setting Communication ID COMM ID SETTING 'ENT' DISPLAY CURRENT SET 'ENT' ENTER NEW COMM ID This is communication ID setting menu. COMM ID SETTING To change the communication ID, press <ENT> key. The number on the LCD is the current communication ID(Device No.). COMM ADDRESS Press <ENT>...
  • Page 26 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.6 Setting Duress Mode DURESS MODE SET NOT USE SELECT KEY 'ENT' IF USE DURESS MODE DURESS P/W DISPLAY CURRENT P/W 'ENT' ENTER NEW P/W You can select whether the Duress mode is used or not. The lower line on the DURESS MODE SET LCD indicates the current mode.
  • Page 27 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.7 Adjusting Communication Speed BAUD RATE 4800 SELECT KEY 9600(DEFAULT) SELECT KEY 'ENT' 19200 SELECT KEY 38400 The number on the LCD is the current communication speed in Baud rate. BAUD RATE Press <ENT> key to adjust the speed. 4800 Available speeds are 4800bps, 9600bps and 19200bps and the default value BAUD RATE...

  • Page 28: Event Clear

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.8 Clearing Event Data Buffer EVENT CLEAR YES ('1' KEY) 'ENT' NO ('0' KEY) Used to erase ALL of the event data such as the permitted access and denied EVENT CLEAR access records. If you want to do so, press <ENT> key. When this figure appears on the LCD, press <1>...

  • Page 29: Initializing The System

    ID TECK STAR FINGER007 ACCESS CONTROLLER Press <ENT> key to change the current Master ID. You should use the new MASTER ID CHANGE Master ID to access the setup menu since the change is finished. A fingerprint for the new Master card is needed to be scanned. Scanning …...
  • Page 30 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.11 Clearing Card Ids ID CLEAR YES ('1' KEY) 'ENT' NO ('0' KEY) Used to erase ALL the card ID data and fingerprint data stored in the device. If CARD ID CLEAR you want to do so, press <ENT> key. When this figure appears on the LCD, press <1>...
  • Page 31 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.1.13 Selecting ID Input mode ENABLE RF_PIN_INPUT SELECT KEY 'ENT' NOT USE FINGER007P DISABLE You can enable PIN(card number) to be input through the keypad, so that RF_PIN_INPUT someone who doesn't carry RF cards with him can access the door. When it is ENABLE disabled, accessing the door by keypad will be denied.
  • Page 32 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.2 Setup Menu F2 SETUP F2 MENU INDEX : 01 ~ 10 WEEKLY : HOL, SUN, MON,.., SAT NO. : 01 ~ 0 5 TIME SCHEDULE SEARCHING KEY INDEX : 01 ~ 10 NO.

  • Page 33: Time Schedule

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.2.1 Registering and Changing Time Schedule TIME SCHEDULE 'ENT' DISPLAY CURRENT T/S SELECT T/S NUMBER AND INDEX (USE "2","8","4","6" KEY) 'ENT' ENTER T/S(8 DIGIT) (START TIME - END TIME) COMPLETE? 'ESC' You may program time schedules to grant and restrict access for each user. TIME SCHEDULE There can be up to ten different schedules.
  • Page 34 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.2.2 Registering and Changing Holiday Time Schedule HOLIDAY T/S 'ENT' DISPLAY CURRENT T/S SELECT T/S NUMBER AND INDEX (USE "2","8","4","6" KEY) 'ENT' ENTER T/S(4 DIGIT) (MM:DD) COMPLETE? 'ESC' You can register up to 32 specified “holidays”, per year for each schedule HOLIDAY T/S setting.
  • Page 35 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.2.3 Defining Outputs in Compliance with Inputs 'ENT' DISPLAY CURRENT SET IN/OUT DEFINE SELECT INDEX (USE "4","6"KEY) 'ENT' ENTER NEW TIME OR T/S INDEX (10 DIGIT OR EVEN DIGIT AND ENT) COMPLETE? 'ESC' You can set each outputs to be generated or not and how long they will last in IN/OUT DEFINE seconds, respectively.
  • Page 36 ID TECK STAR FINGER007 ACCESS CONTROLLER Table 1 : The relation between index(source, Input and Output(default) Index No Relay1 Relay2 TTL1 TTL2 Buzzer [1] Exit button [2] Door contact [3] AUX1 [4] AUX2 [5] Tamper S/W [6] R1 ID OK [7] R1 ID Error [8] R1 T/S Error [9] R1 APB Error...
  • Page 37 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.2.4 Setting Holiday Index 'ENT' ENTER NEW INDEX HOLIDAY INDEX You should choose which Holiday time schedule(date registration set) is to be HOLIDAY INDEX applied. The default index is “00”. Choose the schedule you programmed(1~10). If necessary, press <ENT>...
  • Page 38 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.3 Setup Menu F3 On setup menu F3, there are functions to register additional IDs, to delete registered IDs and to display the registered IDs. FINGER007-20011128...
  • Page 39 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.3.1 Registering IDs 'ENT' REGISTRATION SELECT ID REGISTRATION FINGER007 (FINGER007) CARD or KEY ? CARD APPROACH CARD ERROR DISPLAY 'ENT' ENTER NEW ID FINGER007P (4 DIGIT) MASTER ID ? INPUT P/W, T/S, DOOR_FLAG, FINGER_FLAG FINGER_FLAG = 1 ? USE FINGERPRINT? EXIST ID?
  • Page 40 ID TECK STAR FINGER007 ACCESS CONTROLLER This is ID registration menu. ID REGISTRATION To register additional ID, press <ENT> key. ID Number is registered in the controller by RF cards or through the keypad. CARD & Key Use For RF cards, Press <1>key, the keypad, <2>key, or you can quit the registration by pressing <ESC>key.
  • Page 41 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.3.2 Deleting IDs INPUT ID or APPROACH CARD ID DELETE (FINGER007) 'ENT' INPUT ID (4 DIGIT) (FINGER007P) SUCCESS ? DISPLAY ERROR To delete some registered IDs, press <ENT> key. ID DELETE Enter the eight-digit ID number or approach card that you want to delete. Then Enter Card No.
  • Page 42 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.3.3 Listing Registered IDs ID LIST 'ENT' MEMORY EMPTY EXIST ID ? DISPLAY DISPLAY ID NUMBER, P/W, T/S DOOR_FLAG, FINGER_FLAG 'ESC' SEARCHING ID (USE SEARCHING KEY) If you want to list the registered Ids, press <ENT> key in this menu. ID LIST This message is displayed when there is no registered users.
  • Page 43 ID TECK ACCESS CONTROLLER STAR FINGER007 14.3.4 ID Count ID COUNT DISPLAY REGISTERED ID COUNT This menu displays the total number of registered IDs. ID COUNT XXXX 14.3.5 Event Count EVENT COUNT DISPLAY CURRENT EVENT COUNT This menu displays the number of stored current event. EVENT COUNT XXXX FINGER007-20011128...

  • Page 44: Setup Menu F4

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.4 Setup Menu F4 SETUP F4 MENU DISPLAY CURRENT F/W VERSION F/W VERSION SEARCHING KEY SRAM TEST SRAM TEST SEARCHING KEY OUTPUT TEST OUTPUT TEST SEARCHING KEY LCD TEST LCD TEST SEARCHING KEY KEYPAD TEST KEYPAD TEST SEARCHING KEY SEARCHING KEY...
  • Page 45 ID TECK STAR FINGER007 ACCESS CONTROLLER 14.4.1 F/W Version F/W VERSION DISPLAY CURRENT F/W VERSION The version of the controller’s firmware is displayed on the LCD. F/W Version Press <4> or <6> key to look for other menus of setup menu F4. 14.4.2 Testing SRAM SRAM TEST 'ENT'...

  • Page 46: Testing Outputs

    ID TECK STAR FINGER007 ACCESS CONTROLLER To test the memory, press <ENT> key. SRAM TEST This message would indicate the SRAM(KM68100C) has problems. In this event, Memory fail !!! contact technical support. Press any key to return to the setup menu. Use <4> key and <6>...
  • Page 47 ID TECK STAR FINGER007 ACCESS CONTROLLER To test the output performances, press <ENT> key. If the output performance OUTPUT TEST has no problems, the test will proceeds as follows : First, the green LED blinks twice as the relay is being shorted and opened twice. The relay ticktack as it works, you can hear the sound.

  • Page 48: Keypad Test

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.4.5 Testing Keypad KEYPAD TEST 'ENT' DISPLAY KEYPAD CHARACTERS ENTER KEY ? ERASE COINCIDENT KEY ENTER ALL KEY ? To test the performance of the keypad, press <ENT> key. KEYPAD TEST When operating normally, pressing the keys on the keypad will display the corresponding letter on the LCD.

  • Page 49: Reader Test

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.4.6 Testing Reader RF SCANNING READER TEST (FINGER007) RF INPUT ? DISPLAY CARD NUMBER 'ENT' ENTER 'ESC' ? DISABLE TEST (FINGER007P) ANY KEY To test the performance of the reader, press <ENT> key. READER TEST NOTE : In case Finger007P, you don’t using this menu.

  • Page 50: Input Test

    ID TECK STAR FINGER007 ACCESS CONTROLLER 14.4.7 Testing Input port DISPLAY CURRENT INPUT STATUS INPUT TEST 'ENT' (EXIT, Door Contract, AUX1, AUX2, Tamper) ENTER 'ESC' ? To test the performance of input ports, press <ENT> key. INPUT TEST The lower line on the LCD indicates the status of the five input signals. Note: INPUT TEST 1.
  • Page 51 ID TECK STAR FINGER007 ACCESS CONTROLLER This message indicates there is a problem with the communication performance. TX data = 0 Check connections and try again. Press any key to return to the setup menu. COMM fail As the test proceeds, you can see the characters being transmitted and COMM test pass !! received.

  • Page 52: Fcc Registration Information

    ID TECK STAR FINGER007 ACCESS CONTROLLER 15. FCC Registration Information FCC REQUIREMENTS PART 15 Caution: Any changes or modifications in construction of this device which are not expressly approved by the manufacturer for compliance could void the user's authority to operate the equipment. NOTE : This device complies with Part 15 of the FCC Rules.

  • Page 53: Warranty And Service

    684-1 Deungchon-dong, Kangsuh-gu, SEOUL 157-030, KOREA Tel. : +82(2) 659-0055 Fax.: +82(2) 659-0086 E-mail: webmaster@idteck.com Web-site: www.idteck.com NOTE : Damage occurring during shipment is deemed the responsibility of the carrier, and claims should be made directly to the carrier. FINGER007-20011128...

  • Page 54: Template

    ID TECK STAR FINGER007 ACCESS CONTROLLER 17. TEMPLATE FINGER007-20011128...
