- Page 1 TS5010...
-
Page 2: Table Of Contents
Contents Important Safety Instructions .....................1 Safety .......................................1 Warning ....................................2 What’s in the Box ........................4 Specifications ........................4 Identifying the Parts ......................5 Main Unit ....................................5 Wireless Subwoofer................................6 Remote Control ...................................6 Preparations ..........................6 Prepare the Remote Control ............................6 Replace the Remote Control Battery ...........................7 Placement and Mounting .....................7 Connections ...........................8 IR (TV's Control Sensor) Socket ............................8... -
Page 3: Important Safety Instructions
Important Safety Instructions and a third grounding prong. The wide CAUTION blade or the third prong is provided for RISK OF ELECTRIC SHOCK your safety. If the provided plug does not fit DO NOT OPEN into your outlet, consult an electrician for replacement of the obsolete outlet. -
Page 4: Warning
• Caution: DO NOT INGEST BATTERY,CHEMICAL BURN HAZARD U s e o f c o n t r o l s o r a d j u s t m e n t s o r The remote control supplied with this performance of procedures other than product contains a coin/button cell battery. -
Page 5: Fcc Information
For U.S. models FCC Information Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” NOTE: • This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 6: What's In The Box
What’s in the Box Main Unit Remote Control Wireless Subwoofer User Manual Wall Bracket/ 2.5mm TV's remote control AC Power Cord 3.5mm audio Cable Silicone pad receiving extension Cable Optical Cable Wall mounting Screw Specifications Soundbar Power Supply AC 100-240V~ 50/60Hz Power Consumption W / <... -
Page 7: Identifying The Parts
Identifying the Parts Main Unit button Switch the unit between ON and STANDBY mode. (SOURCE) button Select the play function. 10 11 (Bluetooth) button Select the Bluetooth mode. Press and hold to activate the pairingfunction in Bluetooth mode or disconnect the existing paired Bluetooth device. -
Page 8: Wireless Subwoofer
Wireless Subwoofer 1 AC~ Socket Connect to power. 2 PAIR button Press activate the pairing function between the main unit and the Subwoofer. PAIR 3 PAIR Indicator Light up solidly when the pairing succeed. Remote Control Switch the unit between ON and STANDBY mode. 2 MUTE Mute or resume the sound. -
Page 9: Replace The Remote Control Battery
Replace the Remote Control Battery The remote control requires a CR2025, 3V Lithium battery. 1. Push the tab on the side of the battery tray towards the tray. 2. Now slide the battery tray out of the remote control. 3. Remove the old battery. Place a new CR2025 battery into the battery tray with the correct polarity (+/-) as indicated. -
Page 10: Connections
735 mm 735 mm Remove the screws Install the wall mounting screws Connections IR (TV's Control Sensor) Socket When the Soundbar is placed in front of the TV, it may block the remote control reception of the TV. If you cannot use the TV remote control. You can use the 2.5mm TV's remote control receiving extension cable (included) to connect to the IR jack on the back of the main unit and the other end to... -
Page 11: Use The Aux Socket
Use the AUX Socket A. Use a RCA to 3.5mm audio cable (not included) to connect the TV’s audio output sockets to the AUX socket on the unit. B. Use a 3.5mm to 3.5mm audio cable (included) to connect the TV’s or external audio device headphone socket to the AUX socket on the unit. -
Page 12: Basic Operation
NOTE: • If the wireless connection fails again, check if there is conflict or strong interference (for example, interference from an electronic device) around your location. Remove these conflicts or strong interferences and repeat the above procedures. • The subwoofer should be within 6m of the soundbar in an open area. •... -
Page 13: Aux/Optical Operation
After the “Pairing” voice prompt and the Blue indicator will flash rapidly. 3 Select “TS5010” in the pairing list. After the “Paired” voice prompt, the system is successfully connected and the Blue indicator will light up solidly. -
Page 14: Listen To Music From Bluetooth Device
• If the device is moved beyond the operational range, when it is brought back, please check if the device is still connected to the player. • If the connection is lost, follow the instructions above to pair your device to the player again. Listen to Music from Bluetooth Device If the connected Bluetooth device supports Advanced Audio Distribution Profile (A2DP), you can listen to the music stored on the device through the soundbar'. -
Page 15: Troubleshooting
Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, review the following before requesting service. • No power Ensure that the AC cord is properly connected. Ensure that there is power at the AC outlet. Press (standby) button on the remote control or soundbar to turn the soundbar on. - Page 16 TCL SUN INC. 4nd floor ZEN Tower building, 1111 Nativiadad A. Lopez st., Ermita, Manila.1000 Tel 0063 2 567 0705 www.tcl.com...
