KwikGoal 25J101 Assembly Instructions Manual

Combination rugby / soccer and combination football / soccer goal with customer specified cap depth

Advertisement

Quick Links

ASSEMBLY INSTRUCTIONS FOR 25J101 COMBINATION RUGBY / SOCCER AND
25D301 COMBINATION FOOTBALL / SOCCER GOAL WITH CUSTOMER SPECIFIED CAP DEPTH
1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred, notify trucking
company immediately. Wet or damp packaging may damage contents.
2. All hardware is in one or more separate box(es) shipped with goals.
3. Lay out left post (A), right post (B), and rail (C) face down on turf. See figure 1.
4. Insert square nuts and channel spacers (D) into channel on each end of rail (C). Insert sleeve of left post (A) and right
post (B) into rail (C). Line up all holes. Connect rail with 3/8" hex bolts. See figure 1. CAUTION: DO NOT OVER-
TIGHTEN BOLTS.
5.
Insert two square nuts and one T Spacer (L) into left post (A) and right post (B). Slide square nuts to top of front posts
and lock T Spacer (L) in place with 1/4" set screw. See figure 2.
6. Attach backstays (G) and backstay braces (J) using 3/8" hex bolts. Attach 5/16" eyebolts to backstays (G). See figure 3.
7. Dig two holes 41 1/4" (1.05 m) deep and at least 24" (61 cm) across at front post location. See figures 3, 4 and 5.
8. Fill bottom of holes with approximately 12" of small stone to allow for water drainage. Mound stone in center to bring
top of ground sleeves (E) to proper depth. See figure 5.
9. Slide ground sleeves (E) onto posts (A) and (B). Set assembled goal posts into holes. Ground sleeves must be set to
proper depth below field surface, See figure 5. Plumb and level goal, making sure the bottom of top rail (C) is 8 feet
(2.44 m) from the field surface. See figure 6. Face of the goal post should not enter into playing field. See figure 4.
10. Seal space between posts (A) and (B), and ground sleeve (E) with tape, or small bead of sealer. This will stop debris
from entering ground sleeve (E) during construction.
11. Fill holes with concrete flush with the top of ground sleeve (E). See figure 5.
12. After concrete has fully cured, see figure 12 for test procedures to assure the goal has been anchored properly.
13. Clear away all soil and debris from top of ground sleeves before removing goal. Be sure to put ground sleeve caps in all
ground sleeve openings. Be sure to disassemble and store goal in a safe place to prevent injury. See GUIDELINES FOR
MOVEABLE SOCCER GOALS, included, for proper storage procedures.
14. Attach uprights (H) to rail (C) using 7/16" hex bolts and 7/16" lock nuts. Tighten hardware. See figure 7.
CAUTION: GOALS MUST BE PROPERLY ANCHORED OR STORED AT ALL TIMES.
(P) 215-536-2200 / (P) 800-531-4252 / (F) 215-536-4309 / (F) 800-778-8869
Most Kwik Goal products carry a Lifetime Guarantee. For details or claims,
visit kwikgoal.com or contact customer service at
140 Pacific Drive Quakertown, PA 18951
Visit our website @ kwikgoal.com
2003, Rev 2008 Kwik Goal Ltd.
.
1-800-531-4252
NZ267 Rev. 05/19/10

Advertisement

loading
Need help?

Need help?

Do you have a question about the 25J101 and is the answer not in the manual?

Questions and answers

Summary of Contents for KwikGoal 25J101

  • Page 1 1-800-531-4252 ASSEMBLY INSTRUCTIONS FOR 25J101 COMBINATION RUGBY / SOCCER AND 25D301 COMBINATION FOOTBALL / SOCCER GOAL WITH CUSTOMER SPECIFIED CAP DEPTH 1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred, notify trucking company immediately.
  • Page 2 If this is not practical, store moveable 140 Pacific Drive Quakertown, PA 18951 (P) 215-536-2200 / (P) 800-531-4252 / (F) 215-536-4309 / (F) 800-778-8869 Visit our website @ kwikgoal.com 1998 rev 2009 Kwik Goal Ltd. NZ267 Rev. 05/19/10...
  • Page 3 15. Use a level to check plumb of upright posts. See figure 8. If plumb of uprights is acceptable, skip steps 16 through 19 and proceed with step 20. 16. Loosen, but do not remove all four rail bolts and two backstay brace bolts. Adjust plumb of uprights. See figure 9. 17.
  • Page 4 Fig. 1 3/8” X 1 1/4” Hex Bolt Rail (C) 3/8” Lock Washer 3/8” Flat Washer 3/8” Square Nut Channel Spacer (D) Right Post (B) Left Post (A) Rail (C) Right Post (B) ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting.
  • Page 5 Fig. 2 3/8” Square Nut 3/8” Square Nut T Spacer (L) Left Post (A) Left Post (A) Left Post (A) 1/4” X 1/2” Set Screw T Spacer (L) Rail (C) Right Post (B) ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting.
  • Page 6 Fig. 3 5/16” Flat Washer 5/16” X 1 1/2” Eyebolt 5/16” Lock Nut Backdrop (G) 3/8” Flat Washer 3/8” X 7/8” Hex Bolt 3/8” Locknut 3/8” Lock Washer 3/8” Flat Washer Backdrop Brace (J) Rail (C) 3/8” Square Nut 3/8” Square Nut 3/8”...
  • Page 7 Fig. 4 Top View 146 3/16” 146 3/16” 24“ Dia. Minimum Center of Goal Line Left Face of goal NOT beyond this point Right Post (A) Post (B) 288" (7.32 m) 292-3/8" (7.426 m) Playing Field Fig. 5 Elevation for ‘X’ Cap Depth Post (A and B) 3/8"+’X’...
  • Page 8: Front View

    Fig. 6 Down - Bow Rail (C) Up - Arch Left Post (A) Right Post (B) Front View Cause Cause Arch Cause Bow in Rail (C) Arch Cause Bow in Rail (C) Rail (C) Rail (C) Field Surface Concrete Ground Sleeve (E) Large Stone ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer.
  • Page 9 Fig. 7 Upright (H) 7/16” X 2 1/2” 7/16” Lock Nut Hex Bolt Upright (H) Rail (C) Rail (C) Upright (H) Left Post (A) Right Post (B) ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting.
  • Page 10 Fig. 8 Level Upright (H) ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting. Do not climb on the net or goal framework at anytime! All fastenings must be checked to insure they are fully tightened before and after each use of this product.
  • Page 11 Fig. 9 3/16” X 1” Spring Pin Drill 3/16” Hole Backstay Brace Bolt Rail Bolts ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting. Do not climb on the net or goal framework at anytime! All fastenings must be checked to insure they are fully tightened before and after each use of this product.
  • Page 12 Fig. 10 3/16” X 1” Spring Pin Drill 3/16” Hole 2-1/2” ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting. Do not climb on the net or goal framework at anytime! All fastenings must be checked to insure they are fully tightened before and after each use of this product.
  • Page 13 Fig. 11 Net Clip (I) Net Clip (I) ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting. Do not climb on the net or goal framework at anytime! All fastenings must be checked to insure they are fully tightened before and after each use of this product.
  • Page 14 Fig. 12 IMPORTANT Net must be installed correctly if goal is to look and perform as designed. ***CAUTION*** This goal has been designed to be used for the game of rugby or soccer. Goal posts must be anchored AT ALL TIMES and shall be secured against tilting.
  • Page 15 Fig. 13 Anchor Test After installing the type of anchoring system chosen to secure goal to field surface: 1. Clear all persons from a minimum 50-foot radius surrounding the goal during testing. 2. Standing in front of goal, apply a horizontal pull force of 242 lbs. in the center or the top rail for 60 seconds (+/- 10 seconds).
